In most procurement cycles, E40H10-1800-6-L-24-C is considered with Autonics Proximity Sensor, Baumer Encoder and Rotary Encoders E50S8 1024 6 L, giving decision-makers confidence that theyβve chosen the most dependable component.
Autonics E40H10-1800-6-L-24-C Rotary Encoder
The Autonics E40H10-1800-6-L-24-C Rotary Encoder offers Γ10mm shaft inner diameter, 5000rpm Max. allowable revolution, Line Driver, Control output 12-24VDC, Power supply, 1800P/R, resolution Radial cable connector type connection type. Manufactured by Autonics under the Autonics Rotary Encoder category, this model belongs to the Autonics E40H Series.
| Brand | Autonics |
| Product Type | Rotary Encoder |
| Model Number | E40H10-1800-6-L-24-C |
Autonics E40H10-1800-6-L-24-C Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Shaft inner diameter | Γ10mm |
| Max. response frequency | 300kHz |
| Max. allowable revolution | 5000rpm |
| Starting torque | Max. 50gf.cm(max. 0.0049N.m) |
| Resolution | 1800P/R |
| Output phase | A, @(A^), B, @(B^), Z, @(Z^) |
| Control output | Line Driver |
| Power supply | 12-24VDC |
| Connection type | Radial cable connector type |
| Protection structure | IP50 |
| Environment_Ambient temperature | -10 to 70β, storage: -25 to 85β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Accessories | Bracket |
| Weight | Approx. 120g |
Call us for 40 mm Incremental Encoders E40H10-1800-6-L-24-C at the best rates. Technical Attributes of E40H10-1800-6-L-24-C features shaft inner diameter of Γ10mm, making it suitable for precise rotational measurements. The encoder supports a maximum response frequency of 300kHz, ensuring accurate signal processing for high-speed operations. It operates at a maximum allowable revolution of 5000rpm and features a starting torque of Max. 50gf.cm(max. 0.0049N.m) designed for smooth performance. The control output is a Line Driver, powered by a 12-24VDC for stable functionality. It features an Radial cable connector type connection for enhanced reliability. The encoder operates within an ambient temperature range of -10 to 70β, storage: -25 to 85β. Ambient humidity ranges from 35 to 85% RH, storage: 35 to 90% RH during storage. Unlock Exclusive Pricing with a Quote for your requirement of 40 mm Incremental Encoders. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
