Autonics E30S4-3000-3-N-5 30 mm Incremental Rotary Encoder
E30S4-3000-3-N-5 is a 30 mm incremental rotary encoder with 3000P/R resolution, Γ4mm shaft, 5VDC supply and 5000rpm speed capability. This Autonics 30 mm Incremental Rotary Encoders model provides A, B, Z output phases, 300kHz max response frequency, NPN open collector output, and IP50 protection with axial cable connection. Manufactured by Autonics, part of Autonics Rotary Encoders, this model belongs to the E30S Series used in Indian industrial automation systems.
| Brand | Autonics |
| Product Type | Rotary Encoder |
| Model Number | E30S4-3000-3-N-5 |
Autonics E30S4-3000-3-N-5 30 mm Incremental Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Shaft outer diameter | Γ4mm |
| Max. response frequency | 300kHz |
| Max. allowable revolution | 5000rpm |
| Starting torque | Max. 20gf.cm(max. 0.00196N.m) |
| Resolution | 3000P/R |
| Output phase | A, B, Z |
| Control output | NPN open collector |
| Power supply | 5VDC |
| Connection type | Axial cable type |
| Protection structure | IP50 |
| Environment_Ambient temperature | -10 to 70β, storage: -25 to 85β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 90% RH |
| Accessories | Γ4mm coupling |
| Weight | Approx. 80g |
The Autonics E30S4-3000-3-N-5 30 mm Incremental Rotary Encoders unit is designed for high-resolution rotational feedback in industrial automation systems. This encoder offers 3000P/R resolution, supports 5000rpm maximum speed, operates on a 5VDC power supply, and delivers NPN open collector output. It belongs to the E30S Series and is applied across Indian industrial automation installations.
In application environments, the E30S4-3000-3-N-5 is integrated into conveyors, packaging machines, automated assembly equipment, and compact motion control systems. The encoder supports accurate speed and position monitoring for PLCs and controllers. Its defined response frequency and low starting torque help maintain stable signal output during continuous automation processes.
The Autonics E30S4-3000-3-N-5 rotary encoder aligns with standard incremental feedback requirements in industrial automation. As part of the Autonics E30S Series, it maintains consistent electrical behavior and mechanical compatibility for system integration. This model is selected by engineers and system integrators requiring reliable high-resolution encoder performance in Indian industrial environments.
