Autonics DS40-GS Digital Display Unit
The Autonics DS40-GS Digital Display Unit offers 7-segment LED display method, Green display color, W22.4ΓH40mm size, 12-24VDC power supply. Manufactured by Autonics under the Autonics Digital Display Unit category, this model belongs to theAutonics DS Series.
| Brand | Autonics |
| Product Type | Digital Display Units |
| Model Number | DS40-GS |
Autonics DS40-GS Digital Display Unit β Technical Specifications
| Specification | Value |
|---|---|
| Input method | Serial input |
| Input logic | Positive logic(PNP), Negative logic(NPN) |
| Display method | 7-segment LED |
| Display color | Green |
| Display characters | Displays 64 types of character and sign(0 to 9, A to Z, 27 signs, dot) |
| Character size | W22.4ΓH40mm |
| Current consumption | Max. 40mA |
| Max. Connections | 24 EA |
| Power supply | 12-24VDC |
| Max. Clock | Max. 2kHz |
| Input resistance | 20kΞ© |
| Input level | High: 4.5-24VDC, low: 0-1.2VDC |
| Protection structure | IP40(front panel) |
| Environment_Ambient temperature | -10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 63g(approx. 28g) |
Please speak to our Technical Engineer for Autonics Intelligent Type Digital Display Units DS40-GS at attractive prices. Technical Specs Summary of DS40-GS includes 7-segment LED display, it provides a clear Green color output for easy readability. The display supports Displays 64 types of character and sign(0 to 9, A to Z, 27 signs, dot), making it versatile for various data presentations. With a character size of W22.4ΓH40mm, it ensures excellent visibility in control panels. Powered by 12-24VDC, the unit operates efficiently across a wide range of industrial settings. Designed for durability, it functions within an ambient temperature range of -10 to 55β, storage: -25 to 65β. The humidity tolerance is 35 to 85% RH, storage: 35 to 85% RH, ensuring reliability in different environments. With an ultra-lightweight design at Approx. 63g(approx. 28g) total including accessories, installation is quick and hassle-free. Match Your Needs with a Quote for your requirement of Intelligent Type Digital Display Units. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
