Autonics DPU34B-150A 4-20 mA Power Controller
DPU34B-150A is an Autonics 4-20 mA Power Controller for three-phase 440V systems with 150A rated current industrial automation use. Manufactured by Autonics, this controller belongs to Autonics Power Controllers within the DPU Series, supporting 0β98% phase control, 0β100% cycle ON/OFF control, β€ 60 W power consumption, and optional RS485 communication.
| Brand | Autonics |
| Product Type | Power Controller |
| Model Number | DPU34B-150A |
Autonics DPU34B-150A 4-20 mA Power Controller β Technical Specifications
| Specification | Value |
|---|---|
| Control input | ⒠Auto: 4-20mA / 0-20mA / 0-5VDC @(=) / 1-5VDC @(=) / 0-10VDC @(=) / voltage pulse (0/12VDC @(=)) / no-voltage input (ON/OFF) / Communication input (RS485)⒠Manual: inside 10k⦠VR, outside 3 to 10k⦠VR (min. 2W) |
| Control method | β’ Phase control: Normal control(Non-Feedback), static voltage/static current/static power control(Feedback)β’ Cycle control (Z.C.): Fixed cycle control, Variable cycle controlβ’ ON/OFF control (Z.C.) |
| Output range | Phase control: 0 to 98%, CycleΒ·ON/OFF control: 0 to 100% |
| Power supply | 440V |
| Power consumption | β€ 60 W (control power) |
| Environment_Ambient temperature | -10 to 50 β, storage: -20 to 80 β (no freezing or condensation) |
| Environment_Ambient humidity | 5 to 90 %RH, storage: 5 to 90 %RH (no freezing or condensation) |
| Indicator | R, S, T indicator (green)Operation / manual control indicator (green)DI, alarm / unit (V, A) indicator (red) |
| Number of phase | 3-phase |
| Load | β’ Phase control: resistance load, inductive loadβ’ ON/OFF, Cycle control: resistance load |
| Rated current capacity | 150A |
| Option | Remote Display Unit + RS485 Communication |
| Size | 80~200A |
| Unit weight (packaged weight) | β 11.5 kg (β 13.0 kg) |
The Autonics DPU34B-150A 4-20 mA Power Controller is designed for regulated power output in industrial automation systems. This Autonics controller operates on a three-phase 440V power supply with a 150A rated current capacity and supports phase control and cycle ON/OFF control. DPU34B-150A is part of the DPU Series and is used where precise current-based power regulation is required.
The DPU34B-150A Autonics 4-20 mA Power Controller is applied in conveyors, packaging machinery, automated production lines, and industrial assembly systems. Its 4-20 mA control input enables stable output regulation from PLCs and process controllers. Optional remote display and RS485 communication support centralized monitoring and controlled operation across continuous industrial processes.
DPU34B-150A from Autonics provides defined electrical ratings, controlled power consumption, and standardized communication capability suited for industrial use. As a member of the DPU Series, it supports dependable three-phase power control with specified output ranges. With clear operating parameters and proven brand reliability, the DPU34B-150A Autonics 4-20 mA Power Controller remains suitable for long-term industrial automation applications.
