Autonics CT6S-2P4T Counter
The Autonics CT6S-2P4T Counter offers 1, 30, 1k, 5k, 10k [cps] counting speed, 100-240VAC~ 50/60Hz power supply, Terminal block, 2-stage preset control output. Manufactured by Autonics under the Autonics Counters category, this model belongs to the Autonics CT6S Series.
| Brand | Autonics |
| Product Type | Counter |
| Model Number | CT6S-2P4T |
Autonics CT6S-2P4T Counter β Technical Specifications
| Specification | Value |
|---|---|
| Display method | 6-digit 7-segment LED |
| Max. Counting Speed | 1, 30, 1k, 5k, 10k [cps] |
| Counter_Counting range | -99999 to 999999 |
| Min. signal Width | 1ms/20ms |
| Power supply | 100-240VAC~ 50/60Hz |
| External Power Supply | Max. 12VDC @(=) Β±10%, 100mA |
| Operation method | Counter: Count up, Count down, Count up/downTimer: Count up, Count down |
| Terminal | Terminal block |
| Output Operation | SIGNAL ON DELAY, POWER ON DELAY, FLICKER, INTERVAL, SIGNAL OFF DELAY, ON-OFF DELAY, INTEGRATION TIME |
| Time operation | POWER ON STARTSIGNAL ON START |
| Signal Input Method | Voltage input(PNP), No-voltage input(NPN) |
| Setting range | 0.001 sec to 9.999 sec, 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 9999 min, 1 min to 99 hour 59 min, 1 hour to 9999 hour |
| Control output_Type | 2-stage preset |
| Control output_Relay | SPST (1a): 2 |
| Counter_Scale | Decimal point up to fifth digit |
| Counter_Min. input signal width | RESET: Selectable 1ms/20ms |
| Timer_Min. input signal width | INA, INH, RESET: Selectable 1ms/20ms |
| Communication output | RS485 |
| Memory Protection | Approx. 10 years |
| Environment_Ambient temperature | -10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP65(front panel) |
| Weight | Approx. 212g (approx. 159g) |
The Autonics CT6S-2P4T Counter delivers advanced functionality as a Programmable Digital Counter and Timer with a 6-digit LED display and counting speeds ranging from 1 cps to 10k cps. Designed for flexibility, it supports both PNP and NPN inputs, selectable signal widths, and comes with RS485 communication for seamless PLC and SCADA connectivity. With IP65-rated protection and a 10-year memory backup, the CT6S automation counter from Autonics provides reliable performance in harsh industrial environments where accuracy and durability are essential.
In real-world automation, the Autonics CT6S 2P4T model is used in conveyor systems, packaging units, and batching machines to manage timing and event counting effectively. It provides two-stage preset outputs, multiple delay modes, and easy terminal block wiring, reducing installation complexity. At just 212g, this counter signal device CT6S integrates smoothly into control panels and enhances productivity by maintaining stable operation under continuous use. Engineers and plant operators trust it for minimizing downtime and improving precision in production.
The CT6S series of Autonics counters is known for stability, adaptability, and simple configuration. This Autonics CT6S-2P4T programmable counter is valued across industries for long-term reliability and easy integration into process control. Buyers searching for solutions under CT6S automation series, Autonics CT6S counter range, or CT6S 2P4T industrial counters will find this model to be a dependable choice. For detailed specifications, visit the official Autonics Counters resource page.
