Autonics CH20-HP020-1R Cables

Name: Autonics CH20-HP020-1R
Brand: Autonics
SKU: CH20-HP020-1R
Rating: 4.8 (4 reviews)

The Autonics CH20-HP020-1R Cables offers 20-pin connector pins, UL 20276 TWIST 20C applicable cable, ≤1A current, 500VAC~ 50/60Hz for 1 min. voltage. Manufactured by Autonics under the Autonics Cables category, this model belongs to the Autonics CH Series.

Datasheet

Brand	Autonics
Product Type	Cables
Model Number	CH20-HP020-1R

Autonics CH20-HP020-1R Cables – Technical Specifications

Specification	Value
Number of connector pins	20-pin
Connector for PLC	Hirose 20pin socket
Connector for terminal block	Hirose 20pin socket
Applicable cable	UL 20276 TWIST 20C
Conductor characteristics	7/0.127mm(AWG 28)×10P
Insulation diameter	0.12mm²
Cable diameter	Ø6.3mm(26C)
Rated current	≤1A
Conductor resistance	≤0.223Ω/m
Insulation voltage	500VAC~ 50/60Hz for 1 min.
Insulation resistance	≥15MΩ/km
Environment_Ambient temperature	-15 to 55℃, storage: -25 to 65℃
Environment_Ambient humidity	35 to 85% RH, storage: 35 to 85% RH
Weight	Approx. 124g
