Autonics BY500-TDT1,2 Photoelectric Sensor
The Autonics BY500-TDT1,2 Photoelectric Sensor offers Through-beam type(standard type) sensing type, 500mm, Infrared LED(940nm), NPN open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BY Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BY500-TDT1,2 |
Autonics BY500-TDT1,2 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type(standard type) |
| Sensing distance | 500mm |
| Sensing target | Opaque material of min. Γ5mm |
| Response time | Max. 1ms |
| Light source | Infrared LED(940nm) |
| Operation mode | Dark ON |
| Power supply | 12-24VDC |
| Current consumption | Emitter/Receiver: Max. 30mA |
| Control output | NPN open collector |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -10 to 60β, storage: -25 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP50 |
| Connection type | Cable type(Γ4, 2m) |
| Material | Case: PC, sensing part: PC, bracket: SPCC, bolt: SCM, nut: SCM |
| Weight | β 150 g (β 200 g) |
The Autonics BY500-TDT1,2 Compact Synchronous Photo Sensor is built for accurate object detection in industrial environments. Using a through-beam type sensing method, it detects opaque materials as small as Γ5mm over a 500mm range. Its infrared LED (940nm) light source combined with Dark ON operation mode ensures stable performance even in challenging ambient lighting conditions up to 11,000 lx sunlight and 3,000 lx incandescent light.
With a fast 1ms response time and 12β24VDC Β±10% operating range, the BY500-TDT1,2 supports high-speed automation without compromising accuracy. Power consumption is limited to 30mA for efficiency. An NPN open collector output allows easy integration with PLCs and control systems. The IP50-rated PC housing, along with SPCC and SCM hardware, offers solid resistance against dust and industrial wear.
The cable-type connection (Γ4 mm, 2 m) simplifies installation in tight machine layouts. For full technical details, visit the Autonics Sensors & Controllers page or explore the complete Autonics Photoelectric Sensors catalog.
By combining precision sensing, durability, and flexibility, the Autonics BY500-TDT1,2 delivers reliable performance across industries β from automotive assembly lines to logistics warehouses β reinforcing its reputation as a trusted choice in industrial automation.
