Autonics BX700-DFR-T Photoelectric Sensor
The Autonics BX700-DFR-T Photoelectric Sensor offers Diffuse reflective type sensing type, 700mm, Infrared LED(940nm), Relay output, 24-240VAC~ Β±10% 50/60Hz, 24-240VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BX Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BX700-DFR-T |
Autonics BX700-DFR-T Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Diffuse reflective type |
| Sensing distance | 700mm |
| Sensing target | Opaque, Translucent material |
| Response time | Max. 20ms |
| Light source | Infrared LED(940nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by switch) |
| Power supply | 24-240VAC~ Β±10% 50/60Hz, 24-240VDC |
| Current consumption | Max. 3VA |
| Control output | Relay |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -20 to 55β, storage: -25 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP66 |
| Connection type | Terminal block type |
| Material | Case, Lens cover: Polycarbonate, Sensing part: Acrylic, Bracket: Steel plate cold commercial,Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum |
| Timer function | Timer Function |
| Accessories_Common | Adjuster driver, Fixing bracket, Bolts, Nuts |
| Hysteresis(distance) | Max. 20% at sensing distance |
| Weight | Approx. 116g |
Autonics BX700-DFR-T is engineered as a diffuse reflective photoelectric sensor with a wide sensing distance of 700mm, offering precise detection of opaque and translucent objects. It uses a high-quality 940nm infrared LED as its light source and delivers a fast 20ms response time, making it suitable for automated conveyors, packaging, and sorting tasks. Powered by a universal 24β240VAC/DC supply with only 3VA consumption, the BX700-DFR-T ensures energy efficiency and flexibility across both legacy and modern systems. Its relay output simplifies integration with different PLCs, while the terminal block connection provides secure and easy wiring. With IP66 protection, a durable polycarbonate and acrylic body, and a built-in sensitivity adjuster, this model is built for long-lasting reliability in dusty or wet industrial environments.
The Autonics BX700-DFR-T is commonly used in conveyor systems, pallet detection, and product positioning, where consistent object sensing is critical. Engineers prefer this Universal AC/DC Photoelectric Sensor for carton counting, package alignment, and object verification, even under challenging ambient light. Junior technicians benefit from its simple installation, while experienced maintenance teams rely on its robustness and stable performance. Its reliability across multiple applications makes the BX700-DFR-T a trusted choice for diverse automation setups.
The BX700-DFR-T, often searched as BX700 or referenced through the Autonics BX700-DFR-T manual, is valued by buyers for its stable long-range detection and integration flexibility. As part of the advanced Autonics lineup, this diffuse reflective photoelectric sensor provides engineers with accurate, energy-efficient performance in high-speed automation. For detailed documentation and additional resources, visit the official Autonics Photoelectric Sensors page.
