Autonics BX5M-MFR-T 12–240 V AC/DC Photoelectric Sensor
BX5M-MFR-T is an Autonics 12-240 V AC/DC photoelectric sensor with 5 m retroreflective sensing distance for industrial automation applications. Manufactured by Autonics, this sensor is part of Autonics Photoelectric Sensors under the BX Series, featuring retroreflective sensing type, 5 m sensing distance, max. 20 ms response time, infrared LED (850 nm), Light ON and Dark ON selection, wide AC/DC power supply range, relay control output, and terminal block connection type.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BX5M-MFR-T |
Autonics BX5M-MFR-T 12–240 V AC/DC Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Retroreflective type(standard type) |
| Sensing distance | 5m(MS-2) |
| Sensing target | Opaque material of min. Ø60mm |
| Response time | Max. 20ms |
| Light source | Infrared LED(850nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by switch) |
| Power supply | 24-240VAC~ ±10% 50/60Hz, 24-240VDC |
| Current consumption | Max. 3VA |
| Control output | Relay |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -20 to 55℃, storage: -25 to 70℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP66 |
| Connection type | Terminal block type |
| Material | Case, Lens cover: Polycarbonate, Sensing part: Acrylic, Bracket: Steel plate cold commercial,Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum |
| Timer function | Timer Function |
| Accessories_Common | Adjuster driver, Fixing bracket, Bolts, Nuts |
| Accessories_Individual | Reflector(MS-2) |
| Weight | Approx. 131g |
BX5M-MFR-T Autonics 12-240 V AC/DC Photoelectric Sensor is used for stable object detection in industrial automation environments. This Autonics 12-240 V AC/DC photoelectric sensor operates using retroreflective sensing with a 5 m sensing distance and an infrared LED (850 nm) light source. It supports Light ON and Dark ON operation and maintains a maximum response time of 20 ms. BX5M-MFR-T belongs to the Autonics BX Series used across industrial automation systems.
The BX5M-MFR-T Autonics 12-240 V AC/DC Photoelectric Sensor is commonly installed in conveyors, packaging machinery, automated assembly lines, and material handling systems. Its retroreflective sensing method enables consistent detection using reflectors, while the relay output allows direct integration with control circuits. The wide AC/DC power compatibility supports reliable operation across diverse industrial electrical environments.
BX5M-MFR-T Autonics 12-240 V AC/DC Photoelectric Sensor combines defined sensing distance, controlled response time, and dependable relay output for industrial automation use. As part of the Autonics BX Series, it reflects the brand’s established reliability in photoelectric sensing solutions. With its infrared LED light source, selectable operation modes, and terminal block connection, BX5M-MFR-T remains suitable for long-term operation in Indian industrial environments.
