Autonics BX15M-TFR-T Photoelectric Sensor
The Autonics BX15M-TFR-T Photoelectric Sensor offers Through-beam type sensing type, 15m, Infrared LED(850nm), Relay output, 24-240VAC~ Β±10% 50/60Hz, 24-240VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BX Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BX15M-TFR-T |
Autonics BX15M-TFR-T Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type |
| Sensing distance | 15m |
| Sensing target | Opaque material of min. Γ15mm |
| Response time | Max. 20ms |
| Light source | Infrared LED(850nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by switch) |
| Power supply | 24-240VAC~ Β±10% 50/60Hz, 24-240VDC |
| Current consumption | Emitter/Receiver: Max. 3VA |
| Control output | Relay |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -20 to 55β, storage: -25 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP65 |
| Connection type | Terminal block type |
| Material | Case, Lens cover: Polycarbonate, Sensing part: Acrylic, Bracket: Steel plate cold commercial,Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum |
| Timer function | Timer Function |
| Accessories_Common | Adjuster driver, Fixing bracket, Bolts, Nuts |
| Weight | Approx. 226g |
The Autonics BX15M-TFR-T operates on a through-beam sensing principle with an impressive 15m detection range, capable of sensing opaque targets of Γ15mm or larger. It utilizes an 850nm infrared LED light source and delivers a fast 20ms maximum response time, enabling stable performance in material handling and factory automation lines. This Universal AC/DC Photoelectric Sensor supports both 24β240VAC and 24β240VDC power, consuming only 3VA, which ensures compatibility with legacy relay systems and modern PLCs alike. With selectable Light ON/Dark ON modes and a sensitivity adjustment dial, engineers can fine-tune the output to match varying production requirements. The relay output provides reliable switching capability, while the IP65-rated enclosure with polycarbonate housing and acrylic optics ensures protection against dust, oil, and water spray. Designed to operate in temperatures from -20Β°C to 55Β°C, the BX15M-TFR-T offers durability for demanding Indian factory conditions. Its terminal block design, complete with mounting brackets and adjustment tools, allows wholesalers, dealers, and distributors to supply a sensor that is simple to install and trusted for continuous industrial use.
The BX15M-TFR-T Photoelectric Sensor is widely adopted in conveyor automation, packaging inspection, and warehouse systems where long-range detection is essential. Engineers rely on its stable 15m sensing capability to monitor cartons, pallets, and heavy objects with accuracy. Maintenance teams appreciate its rugged build, while automation buyers often search for BX15M and Autonics BX15M when selecting reliable sensors. Built with efficiency and endurance, the Autonics BX15M-TFR-T continues to support Indian industries with trusted performance.
Industrial buyers recognize the Autonics BX15M-TFR-T as a dependable model in long-distance sensing applications, offering versatility through AC/DC operation and rugged IP65 protection. Preferred by wholesalers, dealers, and distributors, this sensor combines accuracy, durability, and ease of integration into automation systems. For detailed specifications and datasheets, visit the Autonics Photoelectric Sensors page.
