Autonics BWPK25-05P Area Sensor
The Autonics BWPK25-05P Area Sensor offers Through-beam type(direct beam) sensing, Long distance mode: 0.1 to 3mShort distance mode: 0.05 to 1m sensing distance, Infrared LED(850nm modulated) light source, 12-24VDC power supply , PNP open collector output. Manufactured by Autonics under the Autonics Area Sensor category, this model belongs to the Autonics BWP Series.
| Brand | Autonics |
| Product Type | Area Sensor |
| Model Number | BWPK25-05P |
Autonics BWPK25-05P Area Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type(direct beam) |
| Sensing distance | Long distance mode: 0.1 to 3mShort distance mode: 0.05 to 1m |
| Light source | Infrared LED(850nm modulated) |
| Optical axis pitch | 25mm |
| Number of optical axes | 5 |
| Sensing height | 100mm |
| Power supply | 12-24VDC |
| Control output | PNP open collector |
| Operation mode | Light ON/Dark ON(set by switch) |
| Environment_Ambient illumination | Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -10 to 55β, storage: -20 to 60β |
| Connection type | Cable type(Γ4, 2m) |
| Protection structure | IP40 |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Min. sensing target | Opaque materials of min. Γ35mm |
| Response time | Max. 30ms |
| Material | Case: Polycarbonate/Acrylonitrile butadiene styrene, Sensing part: Polymethyl methacrylate |
| Cable specification | Γ4.0mm, 4-wire, 2m(emitter: Γ4.0mm, 3-wire, 2m)(AWG 22, core diameter: 0.08mm, number of cores: 60, insulator out diameter: Γ1.25mm) |
| Weight | Approx. 220g(approx. 180g) |
The Autonics BWPK25-05P Slim Body Area Sensor uses a through-beam sensing method, supporting both short-range (0.05β1 m) and long-range (0.1β3 m) detection. It employs a modulated Infrared LED at 850 nm, ensuring stable performance even under strong ambient light conditions.
Featuring a 25 mm optical axis pitch and five optical axes, the sensor achieves a 100 mm sensing height for improved coverage. It delivers a maximum response time of just 30 ms, making it suitable for fast-moving production lines where precise object detection is essential.
Designed with a polycarbonate/ABS housing and rated IP40, the BWPK25-05P withstands industrial environments with temperatures from -10 Β°C to 55 Β°C. It operates on 12β24 VDC Β±10%, includes a PNP open collector output, and offers selectable Light ON/Dark ON modes for flexible integration into automation systems. For more details, visit Autonics Sensors.
