Autonics BWPK25-05 Area Sensor
The Autonics BWPK25-05 Area Sensor offers Through-beam type(direct beam) sensing, Long distance mode: 0.1 to 3mShort distance mode: 0.05 to 1m sensing distance, Infrared LED(850nm modulated) light source, 12-24VDC power supply , NPN open collector output. Manufactured by Autonics under the Autonics Area Sensor category, this model belongs to the Autonics BWP Series.
| Brand | Autonics |
| Product Type | Area Sensor |
| Model Number | BWPK25-05 |
Autonics BWPK25-05 Area Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type(direct beam) |
| Sensing distance | Long distance mode: 0.1 to 3mShort distance mode: 0.05 to 1m |
| Light source | Infrared LED(850nm modulated) |
| Optical axis pitch | 25mm |
| Number of optical axes | 5 |
| Sensing height | 100mm |
| Power supply | 12-24VDC |
| Control output | NPN open collector |
| Operation mode | Light ON/Dark ON(set by switch) |
| Environment_Ambient illumination | Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -10 to 55β, storage: -20 to 60β |
| Connection type | Cable type(Γ4, 2m) |
| Protection structure | IP40 |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Min. sensing target | Opaque materials of min. Γ35mm |
| Response time | Max. 30ms |
| Material | Case: Polycarbonate/Acrylonitrile butadiene styrene, Sensing part: Polymethyl methacrylate |
| Cable specification | Γ4.0mm, 4-wire, 2m(emitter: Γ4.0mm, 3-wire, 2m)(AWG 22, core diameter: 0.08mm, number of cores: 60, insulator out diameter: Γ1.25mm) |
| Weight | Approx. 220g(approx. 180g) |
The Autonics BWPK25-05 uses a through-beam detection system with 5 optical axes spaced at 25mm, delivering accurate detection of opaque materials from 0.05 to 3 meters. Its 100mm sensing height ensures consistent coverage in compact automation setups.
Powered by 12β24VDC (Β±10%) with NPN open collector output, the sensor supports Light ON/Dark ON modes adjustable via a built-in switch. The fast 30ms response time and robust IP40-rated polycarbonate housing guarantee reliable performance even in high-speed industrial operations.
The BWPK25-05 includes a 2-meter cable for easy integration, withstands ambient light up to 10,000lx, and can detect small components as tiny as Γ35mm. Its compact design suits panel integration, sensor arrays, and localized automation tasks.
The BWPK25-05 is ideal for panel integration, conveyor monitoring, and component inspection in industrial automation. Engineers value its adjustable detection modes, fast response, and compact footprint for reliable performance. For precision short-to-mid range sensing, the Autonics BWPK25-05 ensures accuracy, durability, and seamless integration in tight automation environments.
