Autonics BW40-14P Area Sensor
The Autonics BW40-14P Area Sensor offers Through-beam type(direct beam) sensing, 0.1 to 7m sensing distance, Infrared LED(850nm modulated) light source, 12-24VDC power supply , PNP open collector output. Manufactured by Autonics under the Autonics Area Sensor category, this model belongs to the Autonics BW Series.
| Brand | Autonics |
| Product Type | Area Sensor |
| Model Number | BW40-14P |
Autonics BW40-14P Area Sensor โ Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type(direct beam) |
| Sensing distance | 0.1 to 7m |
| Light source | Infrared LED(850nm modulated) |
| Optical axis pitch | 40mm |
| Number of optical axes | 14 |
| Power supply | 12-24VDC |
| Control output | PNP open collector |
| Operation mode | Light ON |
| Environment_Ambient illumination | Ambient light: Max. 10,000lx(receiver illumination) |
| Environment_Ambient temperature | -10 to 55โ, storage: -20 to 60โ |
| Connection type | Cable connector type(ร5, 300mm, M12) |
| Protection structure | IP65 |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Min. sensing target | Opaque material of min. ร50mm |
| Response time | Max. 10ms |
| Material | โข Case: Aluminum, โข Front cover, sensing part: Acrylic |
| Cable specification | ร5mm, 4-wire, 300mm, M12 connector |
| Sensing height/Total length | 520/560mm |
| Accessories | Bracket A: 4, Bracket B: 4, Fixing bolt: 8 |
| Weight | BW40-24: Approx. 2.1kg(approx. 1.4kg) |
The Autonics BW40-14P General Purpose Area Sensor features a through-beam sensing type with a detection range of 0.1 to 7 meters. Its 40mm optical axis pitch and 14 optical beams ensure consistent area coverage for opaque targets as small as ร50mm. This model operates on a 12โ24VDC ยฑ10% power supply and uses a PNP open collector output, supporting Light ON operation mode. The built-in Infrared LED (850nm modulated) enhances stability even in high ambient light up to 10,000lx. With a 10ms response time, it is well-suited for fast-moving applications. The robust IP65-rated aluminum housing protects the sensor in dusty or humid environments. Its 300mm M12 cable connector simplifies installation while maintaining electrical integrity. Overall, the BW40-14P offers a strong balance of durability, precision, and control system compatibilityโmaking it a dependable choice in industrial settings.
The Autonics BW40-14P Area Sensor is used where accurate object detection across wider zones is critical. It performs reliably in automated packaging machines, conveyor systems, pallet positioning, and machine guarding applications. With its ability to detect larger objects up to ร50mm, this model is ideal for zones where precise part presence or absence needs to be confirmed. Engineers often use it to detect boxes, cartons, or components moving along conveyor belts, especially in environments with vibration, noise, or varying light levels. Its sturdy design allows maintenance-free operation in production facilities, warehouses, and automotive assembly units. Industrial automation teams value the BW40-14P for its easy wiring, minimal calibration, and reliable operation. It is a preferred solution when safety, speed, and installation efficiency must be maintained without sacrificing performance. For more details on this model and other sensor solutions, visit the Autonics brand page.
