Autonics BUP-30S Photoelectric Sensor
The Autonics BUP-30S Photoelectric Sensor offers Through-beam type sensing type, 30mm, Infrared LED(940nm), NPN open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BUP Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BUP-30S |
Autonics BUP-30S Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type |
| Sensing distance | 30mm |
| Sensing target | Opaquematerial of min. Γ1.5mm |
| Response time | Max. 1ms |
| Light source | Infrared LED(940nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by control wire) |
| Power supply | 12-24VDC |
| Current consumption | Max. 30mA |
| Control output | NPN open collector |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -25 to 65β, storage: -25 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP66 |
| Connection type | Cable type(Γ4, 2m) |
| Material | Case: Acrylonitrile butadiene styrene, Cap: Polycarbonate |
| Sensing Channel | 1-channel |
| Accessories | Adjuster driver |
| Weight | Approx. 85g |
Built for precision, the Autonics BUP-30S U-shaped Photoelectric Sensor features a through-beam sensing type with a sensing distance of 30mm, ideal for detecting opaque objects as small as Γ1.5mm. It uses a stable infrared LED (940nm) as its light source and responds in under 1ms, ensuring real-time object detection with minimal delay. With Light ON/Dark ON modes selectable via control wire and sensitivity adjustment built-in, it offers versatility for dynamic environments. The sensor runs on a 12β24VDC power supply with low current consumption (max. 30mA), making it energy efficient for continuous operation. Its output is managed via an NPN open collector, compatible with standard control systems.
Engineered to withstand industrial challenges, the BUP-30S is encased in durable ABS and polycarbonate material, offers IP66-rated protection, and operates reliably in ambient temperatures ranging from -25Β°C to 65Β°C. It resists up to 11,000lx sunlight and 3,000lx incandescent light, minimizing false triggers in brightly lit areas. Its cable-type connection (Γ4, 2m) ensures easy installation and long-term stability. With a compact structure and strong resistance to humidity (35β85% RH), this sensor stands out as a trusted choice for high-precision automation systems. For more models and options, visit our Autonics Photoelectric Sensors page.
The Autonics BUP-30S is widely used in industrial machines for position verification, component detection, and product presence sensing in compact conveyor systems. It is especially valuable in sectors like electronics assembly, packaging, material handling, and automotive component feeding, where precision and speed are critical. Maintenance engineers trust this model for its consistent performance in dusty, oily, and bright-light environments. For students and professionals alike, this sensor offers a practical example of efficient photoelectric detection with user-friendly installation and configuration. Its ultra-compact U-shaped body enables precise sensing in limited spaces where traditional sensors may not fitβmaking it a smart upgrade for automation teams looking to enhance reliability without increasing system footprint. To the full range of sensors and automation products from this trusted brand, visit the Autonics brand page.
