Autonics BTS200-MDTL Photoelectric Sensor
The Autonics BTS200-MDTL Photoelectric Sensor offers Retroreflective type sensing type, 10~200mm, Red LED(650nm), NPN open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BTS Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BTS200-MDTL |
Autonics BTS200-MDTL Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Retroreflective type |
| Sensing distance | 10~200mm |
| Sensing target | Opaque material of min. Γ27mm(min. sensing target: opaque material of Γ2mm) |
| Response time | Max. 1ms |
| Light source | Red LED(650nm) |
| Operation mode | Light ON |
| Power supply | 12-24VDC |
| Current consumption | Max. 20mA |
| Control output | NPN open collector |
| Environment_Ambient illumination | Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -20 to 55β, storage: -30 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP67 |
| Connection type | Cable type(Γ2.5, 2m) |
| Material | Case: Polybutylene terephthalate, Sensing part: Polymethyl methacrylate, Bracket: Stainless steel 304,Bolt: Carbon steel wire for cold heading(SWCH10A) |
| Weight | Approx. 45g(approx. 25g) |
The Autonics BTS200-MDTL is a highly reliable retroreflective photoelectric sensor offering a stable sensing range of 10 to 200mm, optimized for detecting opaque materials with a minimum diameter of Γ2mm. It uses a 650nm Red LED as the light source and operates in Light ON mode for consistent object detection. With a fast response time of just 1ms, it ensures timely signal processing in dynamic automation systems. The sensor is powered by a 12β24VDC input and consumes only 20mA, making it energy efficient and easy to integrate into control panels via its NPN open collector output.
Engineered with a tough polybutylene terephthalate case and polymethyl methacrylate sensing part, this model is built to perform in demanding conditions. Its enclosure is rated IP67, ensuring complete protection against dust and water ingress. It remains operational under intense light conditions up to 10,000lx and within a wide temperature range from β20Β°C to 55Β°C. The sensor features a 2-meter Γ2.5mm cable for easy wiring in control panels and field-mounted enclosures. The included stainless steel mounting bracket and carbon steel bolts enhance mechanical stability and installation flexibility in vibration-prone zones.
The BTS200-MDTL is well-suited for packaging machines, bottle detection units, conveyor belt applications, and material alignment systems where compact sensing solutions are required without sacrificing reliability. It is widely adopted by Indian manufacturing plants for its quick setup, minimal maintenance, and long service life. Junior and senior maintenance engineers appreciate the sensorβs robustness, while automation engineers value its plug-and-play performance with PLCs. For more variants in this series, visit the Autonics Photoelectric Sensors section or check the full range on the Autonics brand page.
