Autonics BTS15-LDTD-P Photoelectric Sensor
The Autonics BTS15-LDTD-P Photoelectric Sensor offers Convergent reflective type sensing type, 5 to 15mm, Red LED(650nm), PNP open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BTS Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BTS15-LDTD-P |
Autonics BTS15-LDTD-P Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Convergent reflective type |
| Sensing distance | 5 to 15mm |
| Sensing target | Opaque, Translucent material(min. sensing target: Γ0.15mm) |
| Response time | Max. 1ms |
| Light source | Red LED(650nm) |
| Operation mode | Dark ON |
| Power supply | 12-24VDC |
| Current consumption | Max. 20mA |
| Control output | PNP open collector |
| Environment_Ambient illumination | Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -20 to 55β, storage: -30 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP67 |
| Connection type | Cable type(Γ2.5, 2m) |
| Material | Case: Polybutylene terephthalate, Sensing part: Polymethyl methacrylate, Bracket: Stainless steel 304,Bolt: Carbon steel wire for cold heading(SWCH10A) |
| Hysteresis(distance) | Max. 15% of maximum sensing distance |
| Weight | Approx. 45g(approx. 25g) |
Call us for Ultra-Compact, Slim Type Photo Sensors BTS15-LDTD-P at the best rates. Technical Attributes of BTS15-LDTD-P are the sensor features a diffuse Convergent reflective type with a reliable sensing distance of 5 to 15mm, ensuring precise object detection. Powered by an Red LED(650nm), it operates in Dark ON mode, providing optimal efficiency in diverse environments. The response time is an impressive Max. 1ms, enabling quick and accurate detection. This sensor operates on a 12-24VDC power supply and consumes a maximum current of Max. 20mA. It includes an PNP open collector control output for versatile operation. Designed with durability in mind, the protection structure is rated at IP67, making it suitable for challenging conditions. The connection type features a robust Cable type(Γ2.5, 2m) for easy installation. Unlock Exclusive Pricing with a Quote for your requirement of Ultra-Compact, Slim Type Photo Sensors. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
