Procurement teams shortlist BTF15-BDTD-P with Autonics Proximity Sensor, Autonics Tcn4 Series and Autonics Ben5M Mfr, aligning budget approvals, warranty terms, and multisite availability for smoother rollout across plants.
Autonics BTF15-BDTD-P Photoelectric Sensor
The Autonics BTF15-BDTD-P Photoelectric Sensor offers BGS reflective type sensing type, 1 to 15mm, Red LED(650nm), PNP open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BTF Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BTF15-BDTD-P |
Autonics BTF15-BDTD-P Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | BGS reflective type |
| Sensing distance | 1 to 15mm |
| Sensing target | Opaque, Translucent material(min. sensing target: non-illuminated objects of Γ0.2mm) |
| Response time | Max. 1ms |
| Light source | Red LED(650nm) |
| Operation mode | Dark ON |
| Power supply | 12-24VDC |
| Current consumption | Max. 20mA |
| Control output | PNP open collector |
| Environment_Ambient illumination | Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -25 to 55β, storage: -40 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP67 |
| Connection type | Cable type(Γ2.5, 2m) |
| Material | Case: polybutylene terephthalate, sensing part: polymethyl methacrylate,bracket: SUS304(steel use stainless 304), bolt: carbon steel, sleeve: SUS304(steel use stainless 304) |
| Accessories | Fixing bracket, M2 bolt: 2 |
| Hysteresis(distance) | Max. 5% at sensing distance |
| Weight | Approx. 40g (approx. 25g) |
Get A Quote for Ultra-Compact, Thin Type Photo Sensors BTF15-BDTD-P at the best price. Here are the brief Technical Specifications of BTF15-BDTD-P are the sensor features a diffuse BGS reflective type with a reliable sensing distance of 1 to 15mm, ensuring precise object detection. Powered by an Red LED(650nm), it operates in Dark ON mode, providing optimal efficiency in diverse environments. The response time is an impressive Max. 1ms, enabling quick and accurate detection. This sensor operates on a 12-24VDC power supply and consumes a maximum current of Max. 20mA. It includes an PNP open collector control output for versatile operation. Designed with durability in mind, the protection structure is rated at IP67, making it suitable for challenging conditions. The connection type features a robust Cable type(Γ2.5, 2m) for easy installation. It's Time to get a Quote for your requirement of Ultra-Compact, Thin Type Photo Sensors. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
