Autonics BS5-V2M Photomicro Sensor
The Autonics BS5-V2M Photomicro Sensor offers Through-beam type, 5mm sensing distance, Infrared LED(940nm) light source, 5-24VDC power supply, NPN open collector output control output. Manufactured by Autonics under the Autonics Photomicro Sensor category, this model belongs to the Autonics BS5 Series.
| Brand | Autonics |
| Product Type | Photomicro Sensor |
| Model Number | BS5-V2M |
Autonics BS5-V2M Photomicro Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type |
| Sensing distance | 5mm |
| Sensing target | Opaque |
| Min. sensing target | β₯Γ0.8mmΓ2mm |
| Hysteresis(distance) | β€0.05mm |
| Response time | Light ON: Max. 20γ², Dark ON: Max. 100γ² |
| Response frequency | 2kHz |
| Light source | Infrared LED(940nm) |
| Operation mode | Light ON/Dark ON(set by control wire) |
| Indicator | Operation indicator (red LED) |
| Power supply | 5-24VDC |
| Current consumption | Max. 30mA |
| Control output | NPN open collector output |
| Load voltage | β€30VDC@(=) |
| Load current | Max. 100mA |
| Residual voltage | NPN: β€1.2VDC@(=), PNP: β€ 1.2VDC@(=) |
| Protection circuit | Reverse polarity protection circuit, output overcurrent (short-circuit) protection circuit |
| Insulation resistance | β₯20 MΞ© (250 VDC@(=) megger) |
| Noise immunity | The square wave noise (pulse width: 1γ²) by the noise simulator Β±240VDC@(=) |
| Dielectric strength | Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute |
| Vibration | 1.5mm amplitude (max. acceleration 196m/sΒ²) at frequency of 10 to 2,000Hz in each X, Y, Z direction for 2 hours |
| Shock | 15,000 m/sΒ² (approx. 1,500G) in each X, Y, Z direction for 3 times |
| Environment_Ambient illumination | Fluorescent lamp: Max. 1,000lx(received illumination) |
| Environment_Ambient temperature | -20 to 55β, storage : -25 to 85β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP50 (IEC standard) |
| Connection | Connector type |
| Material | Case: PBT, Sensing part: PC |
| Weight_Body | Approx. 30g |
Engineered by Autonics, the BS5-V2M Photomicro Sensor features a through-beam sensing type with a 5 mm detection range, ensuring accurate identification of small opaque objects. It can reliably detect targets as small as Γ0.8 mm Γ 2 mm, supported by an ultra-low hysteresis of β€0.05 mm. With a rapid response time of 20 Β΅s in Light ON mode and 100 Β΅s in Dark ON mode, it delivers high-speed detection for dynamic automation lines. The sensor operates with a 940 nm infrared LED and provides a response frequency of 2 kHz, enabling stable performance even in fast-moving processes. Built for durability, it operates on 5β24VDC Β±10% power supply, consumes only 30 mA, and provides an NPN open collector output rated up to 30VDC and 100 mA load current. Added protection features like reverse polarity safety, short-circuit output protection, and IP50-rated housing with 3kV dielectric strength ensure stable, long-lasting use in industrial environments.
The Autonics BS5-V2M Photomicro Sensor is widely applied in industries requiring accurate detection of tiny opaque objects in fast production cycles. It is ideal for packaging lines, electronic component detection, counting small parts, and position sensing in conveyor systems. The sensorβs high-speed switching and ability to detect small targets without error make it suitable for precision manufacturing, injection molding, and automated sorting equipment. Maintenance engineers can rely on its vibration and shock resistance, as well as its connector-type design, for quick installation and reliable performance. By combining fast response, low hysteresis, and versatile Light ON/Dark ON modes, the BS5-V2M ensures consistent accuracy in demanding applications where product quality depends on precise sensing.
Trusted by OEMs, system integrators, and maintenance professionals across India, Autonics Photomicro Sensors like the BS5-V2M are valued for their precision, durability, and integration-friendly design. Built with robust materials such as PBT and PC, and tested under stringent vibration, shock, and ambient temperature conditions, this sensor ensures consistent performance in real-world applications. Its balance of technical strength and practical usability makes it one of the most reliable models in the Autonics lineup. To more details, related models, and the full range of automation products, visit the Autonics Sensors & Controllers collection on IndMALL.
