Autonics BS5-P1MD-U Photomicro Sensor
The Autonics BS5-P1MD-U Photomicro Sensor offers , sensing distance, Infrared LED(940nm) light source, 12-24VDC power supply, NPN open collector control output. Manufactured by Autonics under the Autonics Photomicro Sensor category, this model belongs to the Autonics BS5 Series.
| Brand | Autonics |
| Product Type | Photomicro Sensor |
| Model Number | BS5-P1MD-U |
Autonics BS5-P1MD-U Photomicro Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Connection type | Cable type(Γ3, 1m) |
| Light source | Infrared LED(940nm) |
| Operation mode | Dark ON(output ON when button ispushed) |
| Power supply | 12-24VDC |
| Current consumption | Max. 35mA |
| Control output | NPN open collector |
| Environment_Ambient illumination | Fluorescent lamp: Max. 1,000lx(received illumination) |
| Environment_Ambient temperature | -20 to 55β, storage: -25 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP40 |
| Material | Case: Polycarbonate + Glass fiber, Button: Polyoxymethylene, Sleeve: SUS304(steel use Stainless 304) |
| Operation method | Push Button Type |
| Button operation_Stop position | 5.0Β±0.4mm |
| Button operation_Output switching position | 4.0Β±0.5mm |
| Button operation_Operation limit position | Max. 0mm |
| Operation load | Max. 3N(Max. 0.3kgf) |
| External input_Response | Max. 1ms |
| Weight | Approx. 50g(approx. 30g) |
Send Your Inquiry for Push Button Type Photomicro Sensors BS5-P1MD-U with cost-effective solutions. Essential Technical Specs of BS5-P1MD-U are Push Button Type Operation method with a Operation load of Max. 3N(Max. 0.3kgf), ideal for detecting the sensors achieve making them suitable for fast-paced operations. Powered by a Infrared LED(940nm) light source, they operate in Dark ON(output ON when button ispushed) modes selectable via a control wire. With a power supply range of 12-24VDC and current consumption of Max. 35mA, they ensure energy-efficient performance. The NPN open collector control output provides seamless integration. Designed for durability, they function in temperatures from -20 to 55β, storage: -25 to 70β, with IP40 rated protection. Capture the Best Deal with a Quote for your requirement of Push Button Type Photomicro Sensors. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
