Autonics BRQM400-DDTA-P Photoelectric Sensor
The Autonics BRQM400-DDTA-P Photoelectric Sensor offers Diffuse reflective type sensing type, 400mm, Red LED(660nm), PNP open collector output, 10-30VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BRQ Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BRQM400-DDTA-P |
Autonics BRQM400-DDTA-P Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Brand | Autonics |
| Product Category | Photoelectric Sensors |
| Product | BRQM400-DDTA-P |
| Sensing type | Diffuse reflective type |
| Sensing distance | 400mm |
| Sensing target | Opaque, Translucent material |
| Response time | Max. 1ms |
| Light source | Red LED(660nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by control wire) |
| Power supply | 10-30VDC |
| Current consumption | Max. 30mA |
| Control output | PNP open collector |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -25 to 60β, storage: -30 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP67(IEC standard) |
| Connection type | Cable type(Γ4, 2m) |
| Material | γCase: brass, Ni-plateγLens, Lens cover: polymethyl methacrylate acrylic |
| Hysteresis(distance) | Max. 20% at rated sensing distance |
| Weight | Approx. 150g(approx. 70g) |
The Autonics BRQM400-DDTA-P is a high-performance Cylindrical Photoelectric Sensor with a diffuse reflective type design and a reliable 400mm sensing range. It uses a Red LED (660nm) light source for precise object detection and operates in Light ON/Dark ON modes via control wire. With a rapid 1ms response time and PNP open collector output, it integrates easily into modern PLC-based control systems while maintaining stable performance under ambient light conditions up to 11,000lx.
Engineered for durability, this model features a robust IP67 protection structure and a nickel-plated brass housing that resists dust, water, and mechanical wear. Its Γ4, 2m cable connection ensures secure installation in demanding production environments. The sensor operates on a 10β30VDC supply with low current consumption (max. 30mA), making it both energy-efficient and reliable for continuous use in industrial lines. Learn more at Autonics or see the full Autonics Photoelectric Sensors range.
The BRQM400-DDTA-P is ideal for conveyor systems, packaging machinery, electronics assembly lines, and automated quality inspection stations. Its ability to detect opaque and translucent materials makes it versatile for material handling, component positioning, and part verification tasks. With stable output, rugged build, and fast reaction time, it supports smooth, uninterrupted operation, reducing downtime and improving production efficiency in industrial automation projects.
