Autonics BRQM100-DDTA-P Photoelectric Sensor
The Autonics BRQM100-DDTA-P Photoelectric Sensor offers Diffuse reflective type sensing type, 100mm, Infrared LED(850nm), PNP open collector output, 10-30VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BRQ Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BRQM100-DDTA-P |
Autonics BRQM100-DDTA-P Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Brand | Autonics |
| Product Category | Photoelectric Sensors |
| Product | BRQM100-DDTA-P |
| Sensing type | Diffuse reflective type |
| Sensing distance | 100mm |
| Sensing target | Opaque, Translucent material |
| Response time | Max. 1ms |
| Light source | Infrared LED(850nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by control wire) |
| Power supply | 10-30VDC |
| Current consumption | Max. 30mA |
| Control output | PNP open collector |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -25 to 60β, storage: -30 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP67(IEC standard) |
| Connection type | Cable type(Γ4, 2m) |
| Material | γCase: brass, Ni-plateγLens, Lens cover: polymethyl methacrylate acrylic |
| Hysteresis(distance) | Max. 20% at rated sensing distance |
| Weight | Approx. 150g(approx. 70g) |
Autonics BRQM100-DDTA-P is a high-performance Cylindrical Photoelectric Sensor designed with a diffuse reflective type sensing method. It offers a stable 100mm sensing distance, powered by a precise infrared LED (850nm) for accurate detection. With a rapid 1ms response time and adjustable sensitivity, it ensures consistent performance in high-speed automation lines. The rugged IP67-rated brass housing with acrylic lens resists harsh industrial conditions, while its 10β30VDC supply and PNP open collector output make integration simple and efficient.
The Autonics BRQM100-DDTA-P finds wide applications across industries such as packaging, material handling, automotive assembly, and electronics manufacturing. Its compact cylindrical body allows easy mounting in tight spaces, while the 2-meter pre-wired cable ensures secure and stable connections. Maintenance engineers appreciate its durability in environments with dust, oil, and vibration, making it a trusted solution for both indoor and outdoor setups. From conveyor belt object detection to component positioning, this Cylindrical Photoelectric Sensor delivers long-term reliability and reduced downtime, adding measurable value to factory operations.
Engineered with precision, the BRQM100 series highlights Autonicsβ expertise in optical sensing technology. The Autonics BRQM100-DDTA-P offers reliable performance under demanding conditions and provides engineers with a dependable diffuse reflective type sensing solution. Built for industrial automation, this model enhances detection efficiency and reduces errors in production environments. For detailed specifications and similar models, visit the official Autonics Photoelectric Sensors product page.
