Autonics BMS300-DDT-P Photoelectric Sensor
The Autonics BMS300-DDT-P Photoelectric Sensor offers Diffuse reflective type sensing type, 300mm, Infrared LED(940nm), PNP open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BMS Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BMS300-DDT-P |
Autonics BMS300-DDT-P Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Diffuse reflective type |
| Sensing distance | 300mm |
| Sensing target | Opaque, Translucent material |
| Response time | Max. 1ms |
| Light source | Infrared LED(940nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by control wire) |
| Power supply | 12-24VDC |
| Current consumption | Max. 45mA |
| Control output | PNP open collector |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -10 to 60β, storage: -25 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Connection type | Cable type(Γ5, 2m) |
| Material | Case: Acrylonitrile butadiene styrene, Sensing part: Acryl, Bracket: Steel plate cold commercial, Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum |
| Accessories_Common | Fixing bracket, Bolts, Nuts |
| Accessories_Individual | Adjuster driver |
| Hysteresis(distance) | Max. 20% at sensing distance |
| Weight | Approx. 100g |
The Autonics BMS300-DDT-P is a General-Purpose Photoelectric Sensor that ensures reliable detection of opaque and translucent materials up to a 300mm sensing distance. It uses a 940nm infrared LED for accurate performance and offers a quick 1ms response time, making it suitable for fast-paced automation lines. Engineers can choose between Light ON or Dark ON modes via control wire, and the built-in sensitivity adjuster allows fine-tuning in varied detection environments.
Operating on a standard 12β24VDC supply, the sensor consumes a maximum of 45mA and provides a PNP open collector output for direct integration with PLCs and control systems. It is housed in a robust ABS enclosure with acrylic optics and steel mounting hardware, ensuring durability in demanding industrial settings. A 2-meter Γ5mm cable ensures secure wiring, while its performance remains stable across a wide range of environmental conditions β from -10Β°C to 60Β°C and up to 85% RH humidity.
The BMS300-DDT-P is commonly installed in packaging machines, conveyors, inspection stations, and sorting equipment where mid-range, non-contact sensing is essential. Maintenance teams value it for its stable performance and quick installation. For more models from the same brand, visit the Autonics brand page. To view other sensor types, head over to our full selection of Photoelectric Sensors.
