Autonics BM200-DDT Photoelectric Sensor
The Autonics BM200-DDT Photoelectric Sensor offers Diffuse reflective type sensing type, 200mm, Infrared LED(940nm), NPN open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BM Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BM200-DDT |
Autonics BM200-DDT Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Diffuse reflective type |
| Sensing distance | 200mm |
| Sensing target | Opaque, Translucent material |
| Response time | Max. 3ms |
| Light source | Infrared LED(940nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON(option: Dark ON) |
| Power supply | 12-24VDC |
| Current consumption | Max. 40mA |
| Control output | NPN open collector |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -10 to 60β, storage: -25 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Connection type | Cable type(Γ4, 2m) |
| Material | Case: Acrylonitrile butadiene styrene, Sensing part: Acryl, Bracket: Steel plate cold commercial, Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum |
| Hysteresis(distance) | Max. 10% at sensing distance |
The Autonics BM200-DDT Photoelectric Sensor is designed as an Economical General-Purpose Photo Sensor for reliable short-range detection. It offers a 200mm diffuse reflective sensing distance, powered by a 940nm infrared LED, with a fast 3ms response time. Operating on 12β24VDC with 40mA consumption and an NPN open collector output, the BM200-DDT ensures stable integration with automation systems. Its IP-rated construction, ABS body, and steel mounting hardware deliver durability in industrial conditions.
Engineers and maintenance teams rely on the Autonics BM200-DDT for applications like packaging lines, conveyors, and part detection where precision is required. The built-in sensitivity adjuster allows fine-tuning for opaque or translucent targets, while selectable Light ON/Dark ON modes make it adaptable to different PLC logics. With its balance of cost-effectiveness and reliable performance, the BM200-DDT is widely trusted by wholesalers, dealers, and distributors supporting industrial buyers.
Practical in design and proven in performance, the Autonics BM200-DDT Photoelectric Sensor is a dependable choice for Indian industries seeking efficient sensing solutions. Its compact build, low power use, and high detection stability help maintain uptime and reduce maintenance costs. Industrial users benefit from its ability to withstand strong ambient light up to 11,000lx, ensuring accuracy in real-world environments. More details can be found on the Autonics Photoelectric Sensors page.
The Autonics BM200-DDT, also referred to as BM200 or BM200 DDT, is a versatile DDT Photo Sensor trusted for cost-effective automation. Buyers searching for BM 200 or Autonics BM200-DDT prefer it for consistent quality and affordable pricing, making it one of the most reliable Economical General-Purpose Photo Sensors in its class.
