Autonics BL13-TDT Photoelectric Sensor
The Autonics BL13-TDT Photoelectric Sensor offers Through-beam type sensing type, Light ON/Dark ON(set by button), Infrared LED(950nm) NPN open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BL Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BL13-TDT |
Autonics BL13-TDT Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type |
| Response time | Max. 2ms |
| Light source | Infrared LED(950nm) |
| Operation mode | Light ON/Dark ON(set by button) |
| Power supply | 12-24VDC |
| Current consumption | Max. 30mA |
| Control output | NPN open collector |
| Environment_Ambient illumination | Sunlight/Incandescent lamp: Max. 3,000lx for each(received illumination) |
| Environment_Ambient temperature | 10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP64 |
| Connection type | Cable type(Γ2.5, 1m) |
| Material | Case: Polycarbonate |
| Applicable pipe | Using binding band: Γ6 to 13mm,Using protection bracket: Γ12.7mm (1/2 inch) transparent pipe in 1mm thickness (FEP (fluoroplastic) or with equivalent transparency) |
| Accessories | Binding band: 2, Anti-slip tube: 2 |
| Standard sensing target | Liquid in a pipe |
| Weight | Approx. 50g(approx. 13g) |
The Autonics BL13-TDT Liquid Level Photoelectric Sensor uses a through-beam sensing type with a fast 2ms response time for accurate liquid detection in transparent pipes. Powered by a 12β24VDC supply and consuming only 30mA, it features an infrared LED (950nm) for stable performance, even under varying light conditions. The Light ON/Dark ON mode is selectable via a button, allowing easy adaptation to control requirements. Designed with an IP64 protection rating and a durable polycarbonate case, it ensures long service life in industrial environments.
The sensor provides an NPN open collector output, making it compatible with most PLCs and controllers. Its cable type connection (Γ2.5mm, 1m) simplifies installation and reduces downtime. It supports pipe diameters from Γ6 to Γ13mm using the included binding band, and up to Γ12.7mm with a mounting bracket. This flexibility makes it suitable for a wide range of process setups in industries that rely on precision fluid control.
For more about Autonics sensing solutions or other Photoelectric Sensors, visit our dedicated product pages.
The BL13-TDT Liquid Level Photoelectric Sensor is ideal for pharmaceutical filling systems, beverage bottling lines, and lab automation where contamination-free, non-contact sensing is critical. Maintenance engineers value its ability to detect liquid levels without pipe penetration, reducing leak risks and maintaining hygiene. Its quick response supports fast-moving production lines, while its adjustable operation modes make it adaptable to various control logics. The rugged IP64 build ensures consistent performance in dusty or splash-prone environments, making it a trusted choice for both new installations and retrofits.
