Autonics BJX30M-TDT-P Photoelectric Sensor
The Autonics BJX30M-TDT-P Photoelectric Sensor offers Through-beam type sensing type, 30m, Red LED(660nm), PNP open collector output, 10-30VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BJX Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BJX30M-TDT-P |
Autonics BJX30M-TDT-P Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Through-beam type |
| Sensing distance | 30m |
| Sensing target | Opaque material of min. Ø15mm |
| Response time | Max. 1ms |
| Light source | Red LED(660nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by switch) |
| Power supply | 10-30VDC |
| Current consumption | Emitter/Receiver: Max. 20mA |
| Control output | PNP open collector |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -25 to 60℃, storage: -40 to 70℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP65(IEC standard) |
| Connection type | Ø4mm, 3-wire, 2m (emitter of through-beam type: Ø4mm, 2-wire, 2m)(AWG26, core diameter: 0.52mm, number of cores: 20, insulator out diameter: Ø1mm) |
| Material | ㆍCase: polycarbonateㆍLED CAP: polycarbonateㆍLens, Lens cover: polymethyl methacrylate |
| Accessories_Common | Mounting bracket, M3 bolt: 4, adjustment screwdriver |
| Weight | Approx. 145g(approx. 95g) |
Mail Us for your needs in Long Distance Photoelectric Sensor BJX30M-TDT-P with budget-friendly prices. The Main Technical Parameters of BJX30M-TDT-P include the sensor features a diffuse Through-beam type with a reliable sensing distance of 30m, ensuring precise object detection. Powered by an Red LED(660nm), it operates in Light ON/Dark ON(set by switch) mode, providing optimal efficiency in diverse environments. The response time is an impressive Max. 1ms, enabling quick and accurate detection. This sensor operates on a 10-30VDC power supply and consumes a maximum current of Emitter/Receiver: Max. 20mA. It includes an PNP open collector control output for versatile operation. Designed with durability in mind, the protection structure is rated at IP65(IEC standard), making it suitable for challenging conditions. The connection type features a robust Ø4mm, 3-wire, 2m (emitter of through-beam type: Ø4mm, 2-wire, 2m)(AWG26, core diameter: 0.52mm, number of cores: 20, insulator out diameter: Ø1mm) for easy installation. Customize Your Experience with a Quote for your requirement of Long Distance Photoelectric Sensor. Experience the difference with our competitive pricing and superior support over other Suppliers.
