Autonics BJN100-NDT-P Photoelectric Sensor
The Autonics BJN100-NDT-P Photoelectric Sensor offers Narrow beam reflective type sensing type, 70 to 130mm, Red LED(650nm), PNP open collector output, 12-24VDC power supply. Manufactured by Autonics under the Autonics Photoelectric Sensors category, this model belongs to the Autonics BJ Series.
| Brand | Autonics |
| Product Type | Photoelectric Sensor |
| Model Number | BJN100-NDT-P |
Autonics BJN100-NDT-P Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Sensing type | Narrow beam reflective type |
| Sensing distance | 70 to 130mm |
| Sensing target | Opaque, Translucent material(min. sensing target: min. Γ0.2mm(copper wire)) |
| Response time | Max. 1ms |
| Light source | Red LED(650nm) |
| Sensitivity adjustment | Sensitivity adjuster |
| Operation mode | Light ON/Dark ON(set by switch) |
| Power supply | 12-24VDC |
| Current consumption | Max. 30mA |
| Control output | PNP open collector |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -25 to 55β, storage: -40 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP65 |
| Connection type | Cable type(Γ3.5, 2m) |
| Material | Case: Polycarbonate+Acrylonitrile butadiene styrene, LED Cap: Polycarbonate, Sensing part: Polymethyl methacrylate,Bracket: SUS304(steel use stainless 304), Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum,Sleeve: Brass, Ni-plate |
| Accessories | Fixing bracket, M3 Bolts: 2, M3 Nuts: 2, Adjuster driver |
| Hysteresis(distance) | Max. 20% of sensing distance |
| Min. diameter of transmitting spot | Approx. Γ2.5mm |
| Weight | Approx. 45g |
The Autonics BJN100-NDT-P is a compact, high-performance photo sensor designed to provide precise object detection. It uses a narrow beam reflective sensing type with a sensing range of 70 to 130mm, making it highly efficient for a variety of industrial applications. The sensor features a quick response time of 1ms, ensuring rapid and accurate detection in fast-paced environments.
It operates on a 12-24VDC power supply, consuming a maximum current of 30mA. The Red LED (650nm) light source provides reliable performance even under challenging lighting conditions. Additionally, the PNP open collector control output makes it compatible with various automation systems, offering flexibility in integration. With its IP65 protection rating, the BJN100-NDT-P is built to withstand harsh conditions, providing excellent durability and longevity.
Designed to endure a wide range of environmental conditions, this sensor operates in temperatures ranging from -25 to 55Β°C and is resistant to ambient light up to 11,000 lux. Its polycarbonate and ABS housing ensures durability, and its cable type connection allows for easy installation. The BJN100-NDT-P is trusted in industries such as automotive, electronics, and material handling for its precision and reliability.
The Autonics BJN100-NDT-P photoelectric sensor is widely used in applications requiring precise and reliable detection of objects. It is ideal for detecting opaque and translucent materials, with the minimum sensing target being a copper wire of Γ0.2mm. Its versatility in environments with varying light conditions makes it suitable for packaging systems, conveyor belts, and assembly lines, where quick detection is crucial to ensure seamless operations. The sensorβs narrow beam reflective type offers pinpoint accuracy, making it a valuable tool for industrial automation, particularly in the automotive, electronics, and material handling sectors.
