Autonics BF5G-D1-P Fiber Optic Sensor
The Autonics BF5G-D1-P Fiber Optic Sensor offers Green LED(530nm) light source, 50γ², 150γ², 500γ², 4ms, 10ms response time, 12-24VDC power supply, Light ON/Dark ON(set by parameter) operation mode, PNP open collector control output. Manufactured by Autonics under the Autonics Fiber Optic Sensor category, this model belongs to the Autonics BF5 Series.
| Brand | Autonics |
| Product Type | High Performance Fiber Amplifiers |
| Model Number | BF5G-D1-P |
Autonics BF5G-D1-P Fiber Optic Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Dual display |
| Display method | 4-digit 7-segment LED |
| Light source | Green LED(530nm) |
| Response time | 50γ², 150γ², 500γ², 4ms, 10ms |
| Power supply | 12-24VDC |
| Current consumption | Max. 50mA |
| Operation mode | Light ON/Dark ON(set by parameter) |
| Control output | PNP open collector |
| Timer function | OFF, OFF Delay, ON Delay, One-shot(1 to 5000ms) |
| Sensitivity adjustment | Manual Teaching(auto-tuning, 1-point, 2-point, positioning)β» In multiple connection, batch teaching available |
| Protection structure | IP40 |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -10 to 50β, storage: -20 to 70β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | Case: Polybutylene terephthalate, Cover: Polycarbonate |
| Accessories | Connector type wire(Γ4mm, 3-wire, 2m)(AWG22, core diameter: 0.08mm, number of cores: 60, insulator out diameter: Γ1.25mm), Side connector |
| Weight | Approx. 138g(approx. 20g) |
The Autonics BF5G-D1-P is part of the brandβs advanced High Performance Fiber Amplifiers series, engineered for speed, accuracy, and durability. It features a bright dual 4-digit 7-segment LED display for intuitive setup and real-time monitoring. Utilizing a green LED (530nm) as the light source, this model ensures stable operation across variable target surfaces and ambient lighting. With selectable response times of 50γ², 150γ², 500γ², 4ms, and 10ms, it adapts easily to high-speed production environments. Operating on a 12β24VDC Β±10% power supply and consuming max. 50mA, it supports Light ON/Dark ON operation modes and delivers output through a PNP open collector, making it fully compatible with industrial control systems.
The amplifier includes versatile manual teaching modesβauto-tuning, 1-point, 2-point, and positioningβand supports batch teaching in multi-sensor configurations, streamlining setup across complex systems. Built-in timer functions like OFF, ON Delay, OFF Delay, and One-shot (1β5000ms) help fine-tune signal output for specific applications. Designed for harsh industrial conditions, the BF5G-D1-P features an IP40-rated housing made from polybutylene terephthalate and polycarbonate, and operates reliably from -10 to 50Β°C with ambient humidity up to 85% RH. To view more models or technical documentation, visit the Autonics Sensors & Controllers page or explore the complete series at Autonics Fiber Optic Sensors.
Industrial engineers appreciate its compact design, user-friendly display, and advanced teaching modes that minimize configuration time. With its strong build, stable sensing output, and real-time signal feedback, the Autonics BF5G-D1-P consistently improves system uptime and sensing reliability across high-speed industrial applications.
