Autonics BF4R-E Fiber Optic Sensor
The Autonics BF4R-E Fiber Optic Sensor offers Red LED(660nm) light source, Frequency 1: Max. 0.5ms, Frequency 2: Max. 0.7ms response time, 12-24VDC power supply, Light ON/Dark ON(set by ON/OFF button) operation mode, NPN open collector control output. Manufactured by Autonics under the Autonics Fiber Optic Sensor category, this model belongs to the Autonics BF4 Series.
| Brand | Autonics |
| Product Type | Digital Display Fiber Optic Amplifiers |
| Model Number | BF4R-E |
Autonics BF4R-E Fiber Optic Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Type | External synchronization input type |
| Light source | Red LED(660nm) |
| Response time | Frequency 1: Max. 0.5ms, Frequency 2: Max. 0.7ms |
| Power supply | 12-24VDC |
| Current consumption | Max. 45mA |
| Operation mode | Light ON/Dark ON(set by ON/OFF button) |
| Control output | NPN open collector |
| Timer function | - |
| Self-diagnosis output | ON state under unstable sensing(when the target stays for 300ms in unstable level),ON state when control output is short-circuited•Load voltage: Max. 30VDC @(=)•Load current: Max. 50mA•Residual voltage - Max. 1V(load current: 50mA), Ma |
| Cable specification | Ø4mm, 6-wire, 2m(AWG24, core diameter: 0.08mm, number of cores: 40, insulator out diameter: Ø1mm) |
| Input of stop transmission function | Built-in |
| External synchronization function | Built-in(gate/trigger) |
| Sensitivity adjustment | Manual |
| Environment_Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment_Ambient temperature | -10 to 50℃, storage: -20 to 70℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | Case: Heat-resistance acrylonitrile butadiene styrene, Cover: Polycarbonate |
| Accessories | Fixing bracket, Bolts, Nuts |
| Weight | Approx. 120g(approx. 65g) |
Designed for real-time signal processing, the Autonics BF4R-E is a precision Fiber Optic Sensor Amplifier that features an external synchronization input and a reliable Red LED (660nm) light source. With selectable response times of 0.5ms (Frequency 1) and 0.7ms (Frequency 2), this amplifier enables high-speed object detection in automated production lines. It operates on 12–24VDC power with a ripple tolerance of ±10% and consumes only max. 45mA, ensuring energy-efficient, consistent performance across dynamic environments. Sensitivity is adjusted manually, and Light ON/Dark ON modes can be set using the front panel ON/OFF button. The NPN open collector output allows easy integration into PLCs and control systems.
The BF4R-E comes with advanced self-diagnosis output that triggers alerts under unstable sensing or short-circuit conditions, helping prevent unexpected downtime. Its robust housing—made from heat-resistant ABS and polycarbonate—ensures durability in temperatures ranging from -10°C to 50°C and relative humidity up to 85%. This model includes built-in stop transmission and external sync (gate/trigger) functions, enhancing coordination in multi-sensor setups. With a compact 6-wire design and supplied mounting accessories, the BF4R-E is engineered for straightforward installation in tight control panels. For more product details, visit the Autonics Sensors & Controllers page or browse the full series at Autonics Fiber Optic Sensors.
Engineers in industries like electronics, packaging, pharmaceutical, and automotive value this model for its fast response, manual sensitivity control, and stable operation in challenging environments. Whether you are configuring a new sensing station or upgrading an old system, the Autonics BF4R-E ensures dependable, configurable, and intelligent sensing that helps reduce downtime and boost line productivity.
