Autonics BD-030R Displacement Sensor
The Autonics BD-030R Displacement Sensor offers Using power from the amplifier unit. power supply, 1.5 mm amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 2 hours vibration, Case: Polycarbonate, Sensing part: Glass, Cable: Polyvinyl chloride material, Regular reflection light source, 24.9 to 29.7 mm range. Manufactured by Autonics under the Autonics Displacement Sensor category, this model belongs to the Autonics BD Series.
| Brand | Autonics |
| Product Type | Displacement Sensor |
| Model Number | BD-030R |
Autonics BD-030R Displacement Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Power supply | Using power from the amplifier unit. |
| Environment_Ambient temperature | -10 to 50 ℃, Storage: -15 to 60 ℃ (no freezing or condensation) |
| Environment_Ambient humidity | 35 to 85 %RH, storage: 35 to 85 %RH (no freezing or condensation) |
| Vibration | 1.5 mm amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 2 hours |
| Shock | 300m/s² (approx. 30G) in each X, Y, Z direction for 3 times |
| Protection structure | IP67 (IEC Standards, except connector of extension cable) |
| Material | Case: Polycarbonate, Sensing part: Glass, Cable: Polyvinyl chloride |
| Insulation resistance | Over 20MΩ (at 500VDC megger) |
| Noise immunity | Square shaped noise by noise simulator (pulse width: 1㎲) ±500V |
| Dielectric strength | Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute |
| Spot diameter | Near: ≈ 100×100 ㎛Reference: ≈ 100×100 ㎛Far: ≈ 100×100 ㎛ |
| Resolution | 1㎛ |
| Reference distance | 27.3 mm |
| Max. measurement range | 24.9 to 29.7 mm |
| Linearity | ± 0.1% of F.S. |
| Temperature Characteristics | ± 0.05% of F.S./℃ |
| Light source | Red semiconductor laser (wavelength: 660nm, IEC 60825-1:2014) |
| Light Source_Optical method | Regular reflection |
| Light Source_Laser class | Class 1 (IEC/EN), Class I (FDA(CDRH) CFR Part 1002) |
| Laser Pulse duration | Max. 2ms |
| Light Source_Output | Max. 300㎼ |
| Operation indicator | Power indicator: red LED, Laser emission indicator: green LED,NEAR/FAR indicator: green LED |
| Environment_Ambient illumination | Max. Incandescent lamp 10,000 lx |
| Amplifier unit compatibility | BD Series amplifier unit: 1 |
| Weight | ≈ 55 g (≈ 205 g) |
The Autonics BD-030R operates using power from its compatible amplifier unit, ensuring stable performance across industrial environments. It functions efficiently in ambient temperatures from -10 to 50℃ and storage conditions from -15 to 60℃ without freezing or condensation. Its robust construction includes a polycarbonate case, glass sensing part, and polyvinyl chloride cable, providing resilience and long-term reliability.
This sensor is built to endure mechanical stress, tolerating vibrations up to 1.5 mm amplitude at 10–55Hz and shocks of 300m/s² (≈30G) in all X, Y, and Z axes. With a spot diameter of 100×100 µm and resolution of 1 µm, it guarantees precise measurements. Linearity is maintained at ±0.1% F.S., while temperature characteristics remain stable at ±0.05% F.S./℃, making it ideal for critical industrial applications.
The BD-030R utilizes a 660nm red semiconductor laser (Class 1 IEC/EN, FDA Class I) with a regular reflection optical method. LED indicators display power (red), laser emission (green), and NEAR/FAR positions (green). It also offers excellent noise immunity of ±500V, insulation resistance over 20MΩ, and dielectric strength of 1,000 VAC, ensuring reliable operation under harsh conditions. View full specs on Autonics.
The Autonics BD-030R Laser Displacement Sensor is widely used in automated assembly lines, robotic positioning, precision inspection, and quality control systems. Its high resolution and stable measurement make it perfect for detecting minute variations in materials or components. Maintenance engineers and technicians can integrate it with PLCs and automation systems to monitor processes, reduce errors, and optimize production efficiency. Its IP67-rated construction ensures reliable operation even in dusty, humid, or vibration-prone industrial environments, providing long-term durability and minimal downtime.
