Autonics ATS8W-41 Compact Analog Twin Timer
ATS8W-41 is an Autonics Compact Analog Twin Timer operating on wide AC/DC supply with flicker output mode for industrial. Manufactured by Autonics, this timer is listed under the Autonics Timer category and belongs to the ATS Series, supporting flicker output operation, a 0.1 seconds to 10 hours setting range, 8-pin plug terminal, and DPDT or SPDT control output configurations.
| Brand | Autonics |
| Product Type | Timer |
| Model Number | ATS8W-41 |
Autonics ATS8W-41 Compact Analog Twin Timer – Technical Specifications
| Specification | Value |
|---|---|
| Operation method | Time setting |
| Output Operation | FLICKER |
| Time operation | POWER ON START |
| Terminal | 8-pin plug |
| Power supply | 100-240VAC~50/60Hz, 24-240VDC |
| Setting range | 0.1 to 1 sec, 1 to 10 sec, 0.1 to 1 min, 1 to 10 min, 0.1 to 1 hour, 1 to 10 hour |
| Control output | Time-limit DPDT (1c): 2 or Instantaneous SPDT (1c): 1 + Time-limit SPDT (1c): 1 depending on output operation mode |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85%RH |
| Weight | Approx. 100g (approx. 75g) |
The Autonics ATS8W-41 Compact Analog Twin Timer is a time control device designed for flicker-based timing functions in industrial automation systems. This ATS8W-41 Autonics Compact Analog Twin Timer operates using 100–240VAC and 24–240VDC power supply and follows power on start timing logic. It supports flicker output operation and provides selectable timing ranges from seconds to hours. The unit belongs to the ATS Series and is used for structured time-based control.
In industrial automation environments, the ATS8W-41 Autonics Compact Analog Twin Timer is applied in conveyors, packaging machinery, assembly lines, and control panels. It enables controlled flicker signaling, timed switching, and coordinated process indication. The wide timing ranges allow accurate adjustment to different machine cycles, while the defined output contacts support stable and predictable control behavior.
The ATS8W-41 Autonics Compact Analog Twin Timer delivers consistent timing performance based on clearly defined electrical specifications. With broad AC/DC power compatibility, standardized plug-in terminals, and repeatable output behavior, it supports long-term use in industrial control systems. As part of the ATS Series, this timer is suitable for applications requiring reliable twin-timer flicker control in automation environments.
