Autonics ATS8W-11 12 V DC Timer
ATS8W-11 is an Autonics 12 V DC Timer operating on 12VDC supply with flicker output for industrial automation applications. Manufactured by Autonics, this timer is categorized under the Autonics Timer range and belongs to the ATS Series, featuring flicker output operation, 0.1 seconds to 10 hours setting range, 8-pin plug terminal, and DPDT or SPDT control output options.
| Brand | Autonics |
| Product Type | Timer |
| Model Number | ATS8W-11 |
Autonics ATS8W-11 12 V DC Timer β Technical Specifications
| Specification | Value |
|---|---|
| Operation method | Time setting |
| Output Operation | FLICKER |
| Time operation | POWER ON START |
| Terminal | 8-pin plug |
| Power supply | 12VDC |
| Setting range | 0.1 to 1 sec, 1 to 10 sec, 0.1 to 1 min, 1 to 10 min, 0.1 to 1 hour, 1 to 10 hour |
| Control output | Time-limit DPDT (1c): 2 or Instantaneous SPDT (1c): 1 + Time-limit SPDT (1c): 1 depending on output operation mode |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85%RH |
| Weight | Approx. 100g (approx. 75g) |
The Autonics ATS8W-11 12 V DC Timer is a timing control device designed for flicker-based signal control in industrial automation systems. This ATS8W-11 Autonics 12 V DC Timer operates using 12VDC power supply and follows power on start timing logic. It supports flicker output operation and provides selectable timing ranges from seconds to hours. The unit belongs to the ATS Series and is used for stable time-based control.
In industrial automation environments, the ATS8W-11 Autonics 12 V DC Timer is applied in conveyors, packaging machines, assembly lines, and control panels. It enables controlled flicker signaling, timed switching, and coordinated process indication. The selectable timing ranges allow accurate adjustment for different machine cycles, while the defined output configurations ensure predictable signal behavior during continuous operation.
The ATS8W-11 Autonics 12 V DC Timer delivers reliable timing performance based on clearly defined electrical specifications. With low-voltage DC compatibility, standardized plug-in terminals, and consistent output control, it supports long-term use in industrial systems. As part of the ATS Series, this timer is suitable for applications requiring dependable flicker timing and repeatable automation control.
