Autonics ATS11-43D Timer
The Autonics ATS11-43D Timer offers Time setting operation method, SIGNAL ON START time operation, 11-pin plug terminal, 100-240VAC~50/60Hz, 24-240VDC power supply. Manufactured by Autonics under the Autonics Timers category, this model belongs to the Autonics ATS Series.
| Brand | Autonics |
| Product Type | Timer |
| Model Number | ATS11-43D |
Autonics ATS11-43D Timer β Technical Specifications
| Specification | Value |
|---|---|
| Operation method | Time setting |
| Output Operation | SIGNAL ON DELAY, SIGNAL OFF DELAY, SIGNAL ON-OFF DELAY, FLICKER, INTERVAL |
| Time operation | SIGNAL ON START |
| Terminal | 11-pin plug |
| Power supply | 100-240VAC~50/60Hz, 24-240VDC |
| Signal Input Method | No-voltage input(NPN) |
| Min. signal Width | START, INHIBIT, RESET: [No-voltage input] - Short-circuit impedance: Max. 1kΞ©,Residual voltage: Max. 0.5V, Open-circuit impedance: Min. 100kΞ© |
| Setting range | 0.3 to 3 sec, 3 to 30 sec, 0.3 to 3 min, 3 to 30 min, 0.3 to 3 hour, 3 to 30 hour |
| Control output | Time-limit SPDT (1c): 2 |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85%RH |
| Weight | Approx. 95g (approx. 70g) |
Mail Us for your needs in Compact Multi-Function Analog Timers ATS11-43D with budget-friendly prices. The Main Technical Parameters of ATS11-43D include operation method features a SIGNAL ON DELAY, SIGNAL OFF DELAY, SIGNAL ON-OFF DELAY, FLICKER, INTERVAL function, activating upon power application. The time operation is SIGNAL ON START, ensuring reliable switching. The Time setting range spans 0.3 to 3 sec, 3 to 30 sec, 0.3 to 3 min, 3 to 30 min, 0.3 to 3 hour, 3 to 30 hour, which is suitable for precision applications. The terminal type is an 11-pin plug for secure connections. The power supply operates at 100-240VAC~50/60Hz, 24-240VDC, ensuring stable performance. The control output is Time-limit SPDT (1c): 2, optimizing switching functionality. It operates efficiently in an ambient temperature range of -10 to 55β, storage: -25 to 65β. The ambient humidity tolerance is 35 to 85%RH, enhancing longevity in diverse environments. Customize Your Experience with a Quote for your requirement of Compact Multi-Function Analog Timers. Experience the difference with our competitive pricing and superior support over other Suppliers.
