Autonics ATS11-21D Timer
The Autonics ATS11-21D Timer offers Time setting operation method, SIGNAL ON START time operation, 11-pin plug terminal, 24VAC~ 50/60Hz, 24VDC power supply. Manufactured by Autonics under the Autonics Timers category, this model belongs to the Autonics ATS Series.
| Brand | Autonics |
| Product Type | Timer |
| Model Number | ATS11-21D |
Autonics ATS11-21D Timer – Technical Specifications
| Specification | Value |
|---|---|
| Operation method | Time setting |
| Output Operation | SIGNAL ON DELAY, SIGNAL OFF DELAY, SIGNAL ON-OFF DELAY, FLICKER, INTERVAL |
| Time operation | SIGNAL ON START |
| Terminal | 11-pin plug |
| Power supply | 24VAC~ 50/60Hz, 24VDC |
| Signal Input Method | No-voltage input(NPN) |
| Min. signal Width | START, INHIBIT, RESET: [No-voltage input] - Short-circuit impedance: Max. 1kΩ,Residual voltage: Max. 0.5V, Open-circuit impedance: Min. 100kΩ |
| Setting range | 0.1 to 1 sec, 1 to 10 sec, 0.1 to 1 min, 1 to 10 min, 0.1 to 1 hour, 1 to 10 hour |
| Control output | Time-limit SPDT (1c): 2 |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85%RH |
| Weight | Approx. 95g (approx. 70g) |
Call us for Compact Multi-Function Analog Timers ATS11-21D at the best rates. Technical Attributes of ATS11-21D are operation method features a SIGNAL ON DELAY, SIGNAL OFF DELAY, SIGNAL ON-OFF DELAY, FLICKER, INTERVAL function, activating upon power application. The time operation is SIGNAL ON START, ensuring reliable switching. The Time setting range spans 0.1 to 1 sec, 1 to 10 sec, 0.1 to 1 min, 1 to 10 min, 0.1 to 1 hour, 1 to 10 hour, which is suitable for precision applications. The terminal type is an 11-pin plug for secure connections. The power supply operates at 24VAC~ 50/60Hz, 24VDC, ensuring stable performance. The control output is Time-limit SPDT (1c): 2, optimizing switching functionality. It operates efficiently in an ambient temperature range of -10 to 55℃, storage: -25 to 65℃. The ambient humidity tolerance is 35 to 85%RH, enhancing longevity in diverse environments. Unlock Exclusive Pricing with a Quote for your requirement of Compact Multi-Function Analog Timers. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
