Autonics AT8PMN-2 Timer
The Autonics AT8PMN-2 Timer offers Time setting operation method, POWER OFF START time operation, 8-pin plug terminal, 24VAC~ 50/60Hz, 24VDC power supply. Manufactured by Autonics under the Autonics Timers category, this model belongs to the Autonics AT8PSN Series.
| Brand | Autonics |
| Product Type | Timer |
| Model Number | AT8PMN-2 |
Autonics AT8PMN-2 Timer β Technical Specifications
| Specification | Value |
|---|---|
| Operation method | Time setting |
| Output Operation | POWER OFF DELAY |
| Time operation | POWER OFF START |
| Terminal | 8-pin plug |
| Power supply | 24VAC~ 50/60Hz, 24VDC |
| Setting range | 0~0.5sec, 0~1sec, 0~5sec, 0~10sec, 0~0.5min, 0~1min, 0~5min, 0~10min |
| Control output | Time-limit SPDT (1c): 2 |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85%RH |
| Weight | Approx. 100g |
Talk to Our Engineer for Power OFF Delay Analog Timers AT8PMN-2 with exclusive offers. Core System Specifications of AT8PMN-2 are operation method features a POWER OFF DELAY function, activating upon power application. The time operation is POWER OFF START, ensuring reliable switching. The Time setting range spans 0~0.5sec, 0~1sec, 0~5sec, 0~10sec, 0~0.5min, 0~1min, 0~5min, 0~10min, which is suitable for precision applications. The terminal type is an 8-pin plug for secure connections. The power supply operates at 24VAC~ 50/60Hz, 24VDC, ensuring stable performance. The control output is Time-limit SPDT (1c): 2, optimizing switching functionality. It operates efficiently in an ambient temperature range of -10 to 55β, storage: -25 to 65β. The ambient humidity tolerance is 35 to 85%RH, enhancing longevity in diverse environments. Don't Miss Out on a Quote for your requirement of Power OFF Delay Analog Timers. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
