Autonics AT11DN-1 Timer
The Autonics AT11DN-1 Timer offers Time setting operation method, SIGNAL ON START time operation, 11-pin plug terminal, 12VDC power supply. Manufactured by Autonics under the Autonics Timers category, this model belongs to the Autonics AT Series.
| Brand | Autonics |
| Product Type | Timer |
| Model Number | AT11DN-1 |
Autonics AT11DN-1 Timer β Technical Specifications
| Specification | Value |
|---|---|
| Operation method | Time setting |
| Output Operation | SIGNAL ON DELAY, SIGNAL OFF DELAY, SIGNAL ON-OFF DELAY, FLICKER, INTERVAL |
| Time operation | SIGNAL ON START |
| Terminal | 11-pin plug |
| Power supply | 12VDC |
| Signal Input Method | No-voltage input(NPN) |
| Min. signal Width | INHIBIT, START, RESET: Approx. 50ms |
| Setting range | 0.05 to 0.5 sec, 0.1 to 1 sec, 0.5 to 5 sec, 1 to 10 sec, 0.05 to 0.5 min, 0.1 to 1 min, 0.5 to 5 min, 1 to 10 min, 0.05 to 0.5 hour, 0.1 to 1 hour, 0.5 to 5 hour, 1 to 10 hour, 5 to 50 hour, 10 to 100 hour |
| Control output | Time limit DPDT (2c) |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55 β, storage: -25 to 65 β (no freezing or condensation) |
| Environment_Ambient humidity | 35 to 85%RH, Storage: 35 to 85%RH (no freezing or condensation) |
| Unit weight (packaged weight) | β 85 g (β 132.2 g) |
Get A Quote for Multi-Function Analog Timers AT11DN-1 at the best price. Here are the brief Technical Specifications of AT11DN-1 are operation method features a SIGNAL ON DELAY, SIGNAL OFF DELAY, SIGNAL ON-OFF DELAY, FLICKER, INTERVAL function, activating upon power application. The time operation is SIGNAL ON START, ensuring reliable switching. The Time setting range spans 0.05 to 0.5 sec, 0.1 to 1 sec, 0.5 to 5 sec, 1 to 10 sec, 0.05 to 0.5 min, 0.1 to 1 min, 0.5 to 5 min, 1 to 10 min, 0.05 to 0.5 hour, 0.1 to 1 hour, 0.5 to 5 hour, 1 to 10 hour, 5 to 50 hour, 10 to 100 hour, which is suitable for precision applications. The terminal type is an 11-pin plug for secure connections. The power supply operates at 12VDC, ensuring stable performance. The control output is Time limit DPDT (2c), optimizing switching functionality. It operates efficiently in an ambient temperature range of -10 to 55 β, storage: -25 to 65 β (no freezing or condensation). The ambient humidity tolerance is 35 to 85%RH, Storage: 35 to 85%RH (no freezing or condensation), enhancing longevity in diverse environments. It's Time to get a Quote for your requirement of Multi-Function Analog Timers. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
