Autonics ASGF-02-R Signal Light
The Autonics ASGF-02-R Signal Light offers Flashing(Prism Lens)function, 24VAC/DC power supply, Red lens color, Lead wire connection type. Manufactured by Autonics under the Autonics Signal Lights category, this model belongs to the Autonics MS Series.
| Brand | Autonics |
| Product Type | Signal Lights |
| Product | ASGF-02-R |
Autonics ASGF-02-R Signal Light – Technical Specifications
| Specification | Value |
|---|---|
| Function | Flashing(Prism Lens) |
| Current consumption | 0.33A |
| Lens color | Red |
| Dimension | D86mm |
| Power supply(Bulb type) | 24VAC/DC |
| Bulb specification | 24V 8W |
| Flashing rate | 80±10times/minute |
| Connection type | Lead wire connection |
| Cable specification | UL1007/22AWG |
| Storage ambient temperature | -20~70℃ |
| Ambient temperature | -15~40℃ |
| Ambient humidity | 45 to 85%RH |
| Insulation resistance | 100MΩ or more (500VDC megger basis) |
| Vibration | 0.75mm at 10~55Hz |
| Protection structure | IP42 |
Give Us a Call for Autonics D86mm Bulb Revolving Warning Signal Light ASGF-02-R at the lowest pricing. In-depth Technical Analysis of ASGF-02-R are Flashing(Prism Lens), ensuring high visibility and loud alerts. It operates on a Lead wire connection Connection type with a current consumption of 0.33A, making it energy efficient. The lens color is Red, with a dimension of D86mm, providing a compact and durable design. The rotating rate is , ensuring clear signaling. The bulb specification is 24V 8W, offering long-lasting performance. It includes an UL1007/22AWG cable specification for secure connections.
Built for industrial environments, it has a storage temperature range of -20~70℃, an operating temperature of -15~40℃, and a humidity tolerance of 45 to 85%RH. It provides insulation resistance 100MΩ or more (500VDC megger basis) and withstands 0.75mm at 10~55Hz vibration. With an IP42 protection structure, ensures durability. Elevate Your Project with a Quote for your requirement of D86mm Bulb Revolving Warning Signal Light. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
