Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series AH4K-S564W Autonics AH4K-S564W 5-Phase Stepper Motor Driver The Autonics AH4K-S564W 5-Phase Stepper Motor Driver offers 48.5mm motor length, Dual shaft type, Pentagon wire connection, 0.75A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number AH4K-S564W
Autonics AH4K-S564W 5-Phase Stepper Motor Driver β Technical Specifications Specification Value Motor length 48.5mm Shaft type Dual shaft Wire connection Pentagon Rated current 0.75A/Phase Basic Step Angle [FULL/HALF] 0.72ΒΊ/0.36ΒΊ Max. holding torque 4.2kgf.cm Rotor Moment Of Inertia 175gΒ·cmΒ² Winding Resistance 2.6Ξ© Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)Β±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.33A ElectroMagnetic brake_Static friction torque 8kgf.cm ElectroMagnetic brake_Rotation part inertia moment 29Γ10@(^-7)kgf.cmΒ² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 25ms ElectroMagnetic brake_Releasing time Max. 20ms Weight Approx. 0.87kg(approx. 0.6kg)
