Autonics ACR-B40T I/O Terminal Block
The Autonics ACR-B40T I/O Terminal Blocks offers β€250VDC, 250VAC~, 50/60Hz voltage, 40 EA number of terminals, Max. 10A current, 5.0mm terminal pitch. Manufactured by Autonics under the Autonics I/O Terminal Blocks category, this model belongs to the Autonics ASS Series.
| Brand | Autonics |
| Product Type | I/O Terminal Blocks |
| Model Number | ACR-B40T |
Autonics ACR-B40T I/O Terminal Block β Technical Specifications
| Specification | Value |
|---|---|
| Rated voltage | β€250VDC, 250VAC~, 50/60Hz |
| Terminal type | Rising Clamp |
| Terminal pitch | 5.0mm |
| Applicable cable_Solid wire | Γ0.6 to Γ1.25mm(60β only) |
| Applicable cable_Stranded wire | AWG22-16(0.30 to 1.25mmΒ²)(60β only) |
| Number of terminal | 40 EA |
| Rated current | Max. 10A |
| Dielectric strength | 3,000VAC~ 50/60Hz for 1 minute (between open terminals) |
| Common type | Up +COM, Down -COM |
| Stripped wire length | 8 to 10mm |
| Insulation resistance | β₯1,000Mβ¦ (at 500VDC megger) |
| Environment_Ambient temperature | -15 to 55β, storage: -25 to 65β |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Material | CASE, BASE: PC |
| Weight | Approx. 197g(approx. 130g) |
Mail Us for Autonics Rising Clamp Common Terminal Block ACR-B40T at the lowest pricing. Technical Specs Summary of ACR-B40T are β€250VDC, 250VAC~, 50/60Hz rated voltage, ensuring stable and efficient operation. The Rated current is Max. 10A, optimizing energy efficiency. It features a number of connector pins with an 5.0mm terminal pitch, providing secure and reliable connections.
With β₯1,000Mβ¦ (at 500VDC megger) Number of terminalh of 40 EA between Dielectric strength and 3,000VAC~ 50/60Hz for 1 minute (between open terminals), this relay guarantees high electrical safety. It operates within an ambient temperature range of -15 to 55β, storage: -25 to 65β and humidity levels of 35 to 85% RH, storage: 35 to 85% RH, ensuring durability in industrial environments.
Constructed with CASE, BASE: PC brass terminal pins, it is designed for longevity. With an approximate weight of Approx. 197g(approx. 130g), it offers a robust yet lightweight design. Take the First Step with a Quote for your requirement of Rising Clamp Common Terminal Block. Choose us for unparalleled pricing and support over other Dealers & Distributors.
