Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series A4K-M564 Autonics A4K-M564 5-Phase Stepper Motor Driver The Autonics A4K-M564 5-Phase Stepper Motor Driver offers 48.5mm motor length, Single shaft type, Pentagon wire connection, 1.4 current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number A4K-M564
Autonics A4K-M564 5-Phase Stepper Motor Driver β Technical Specifications Specification Value Motor length 48.5mm Shaft type Single shaft Wire connection Pentagon Rated current 1.4 Basic Step Angle [FULL/HALF] 0.72ΒΊ/0.36ΒΊ Max. holding torque 4.2kgf.cm Rotor Moment Of Inertia 175gΒ·cmΒ² Winding Resistance 0.8Ξ© Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)Β±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.33A ElectroMagnetic brake_Static friction torque 8kgf.cm ElectroMagnetic brake_Rotation part inertia moment 29Γ10@(^-7)kgf.cmΒ² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 25ms ElectroMagnetic brake_Releasing time Max. 20ms Weight Approx. 0.85kg(approx. 0.6kg)
