Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series A3K-S545W-S Autonics A3K-S545W-S 5-Phase Stepper Motor Driver The Autonics A3K-S545W-S 5-Phase Stepper Motor Driver offers 47mm motor length, Dual shaft type, Standard wire connection, 0.75A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number A3K-S545W-S
Autonics A3K-S545W-S 5-Phase Stepper Motor Driver – Technical Specifications Specification Value Motor length 47mm Shaft type Dual shaft Wire connection Standard Rated current 0.75A/Phase Basic Step Angle [FULL/HALF] 0.72º/0.36º Max. holding torque 2.4kgf.cm Rotor Moment Of Inertia 68g·cm² Winding Resistance 2.2Ω Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.2A ElectroMagnetic brake_Static friction torque 1.8kgf.cm ElectroMagnetic brake_Rotation part inertia moment 3×10@(^-7)kgf.cm² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 25ms ElectroMagnetic brake_Releasing time Max. 15ms Weight Approx. 0.49kg(approx. 0.4kg)
