Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series A35K-M566W-R5 Autonics A35K-M566W-R5 5-Phase Stepper Motor Driver The Autonics A35K-M566W-R5 5-Phase Stepper Motor Driver offers 93.5mm motor length, Dual shaft type, Pentagon wire connection, 1.4A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number A35K-M566W-R5
Autonics A35K-M566W-R5 5-Phase Stepper Motor Driver β Technical Specifications Specification Value Motor length 93.5mm Shaft type Dual shaft Wire connection Pentagon Rated current 1.4A/Phase Basic Step Angle [FULL/HALF] 0.144ΒΊ/0.072ΒΊ Rotor Moment Of Inertia 280gΒ·cmΒ² Winding Resistance 1.1Ξ© Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)Β±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.33A ElectroMagnetic brake_Static friction torque Min. 8kgf.cm ElectroMagnetic brake_Rotation part inertia moment 29Γ10@(^-7)kgf.cmΒ² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 20ms ElectroMagnetic brake_Releasing time Max. 25ms Max. allowable torque 35kgf.cm Reduction ratio 1:5 Allowable speed range 0 to 360rpm Backlash Β±20'(0.33Λ) Absolute positon error Β±20'(0.33Λ) Lost motion Β±20'(0.33Λ) Weight Approx. 1.4kg(approx. 1.3kg)
