Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series A21K-M596-S Autonics A21K-M596-S 5-Phase Stepper Motor Driver The Autonics A21K-M596-S 5-Phase Stepper Motor Driver offers 68mm motor length, Single shaft type, Standard wire connection, 1.4A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number A21K-M596-S
Autonics A21K-M596-S 5-Phase Stepper Motor Driver β Technical Specifications Specification Value Motor length 68mm Shaft type Single shaft Wire connection Standard Rated current 1.4A/Phase Basic Step Angle [FULL/HALF] 0.72ΒΊ/0.36ΒΊ Max. holding torque 21kgf.cm Rotor Moment Of Inertia 1400gΒ·cmΒ² Winding Resistance 1.76Ξ© Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)Β±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.62A ElectroMagnetic brake_Static friction torque 40kgf.cm ElectroMagnetic brake_Rotation part inertia moment 153Γ10@(^-7)kgf.cmΒ² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 60ms ElectroMagnetic brake_Releasing time Max. 15ms Weight Approx. 2.15kg(approx. 1.7kg)
