Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series A1K-M543 Autonics A1K-M543 5-Phase Stepper Motor Driver The Autonics A1K-M543 5-Phase Stepper Motor Driver offers 33mm motor length, Single shaft type, Pentagon wire connection, 1.4A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number A1K-M543
Autonics A1K-M543 5-Phase Stepper Motor Driver β Technical Specifications Specification Value Motor length 33mm Shaft type Single shaft Wire connection Pentagon Rated current 1.4A/Phase Basic Step Angle [FULL/HALF] 0.72ΒΊ/0.36ΒΊ Max. holding torque 1.3kgf.cm Rotor Moment Of Inertia 35gΒ·cmΒ² Winding Resistance 1.7Ξ© Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)Β±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.2A ElectroMagnetic brake_Static friction torque 1.8kgf.cm ElectroMagnetic brake_Rotation part inertia moment 3Γ10@(^-7)kgf.cmΒ² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 25ms ElectroMagnetic brake_Releasing time Max. 15ms Weight Approx. 0.34kg(approx. 0.25kg)
