Autonics A16K-G569-SB 5-Phase Stepper Motor Driver

Name: Autonics A16K-G569-SB
Brand: Autonics
SKU: A16K-G569-SB
Rating: 4.9 (4 reviews)

The Autonics A16K-G569-SB 5-Phase Stepper Motor Driver offers 115.5mmmotor length, Single shaft type, Standard wire connection, 2.8A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.

Datasheet

Brand	Autonics
Product Type	5-Phase Stepper Motor Driver
Model Number	A16K-G569-SB

Autonics A16K-G569-SB 5-Phase Stepper Motor Driver – Technical Specifications

Specification	Value
Motor length	115.5mm
Shaft type	Single shaft
Wire connection	Standard
Rated current	2.8A/Phase
Basic Step Angle [FULL/HALF]	0.72º/0.36º
Max. holding torque	16.6kgf.cm
Rotor Moment Of Inertia	560g·cm²
Winding Resistance	0.56Ω
Protection structure	IP30
ElectroMagnetic brake_Rated excitation voltage	24VDC @(=)±10%(no-polarity)
ElectroMagnetic brake_Rated excitation current	0.33A
ElectroMagnetic brake_Static friction torque	8kgf.cm
ElectroMagnetic brake_Rotation part inertia moment	29×10@(^-7)kgf.cm²
ElectroMagnetic brake_B type brake	Power on: brake is released, power off: brake is operating
ElectroMagnetic brake_Operating time	Max. 25ms
ElectroMagnetic brake_Releasing time	Max. 20ms
Weight	Approx. 1.73kg(approx. 1.65kg)
