Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series A16K-G569 Autonics A16K-G569 5-Phase Stepper Motor Driver The Autonics A16K-G569 5-Phase Stepper Motor Driver offers 89mm motor length, Single shaft type, Pentagon wire connection, 2.8A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number A16K-G569
Autonics A16K-G569 5-Phase Stepper Motor Driver – Technical Specifications Specification Value Motor length 89mm Shaft type Single shaft Wire connection Pentagon Rated current 2.8A/Phase Basic Step Angle [FULL/HALF] 0.72º/0.36º Max. holding torque 16.6kgf.cm Rotor Moment Of Inertia 560g·cm² Winding Resistance 0.56Ω Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.33A ElectroMagnetic brake_Static friction torque 8kgf.cm ElectroMagnetic brake_Rotation part inertia moment 29×10@(^-7)kgf.cm² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 25ms ElectroMagnetic brake_Releasing time Max. 20ms Weight Approx. 1.55kg(approx. 1.3kg)
