Home Autonics 5-Phase Stepper Motor Driver 5-Phase Series A10K-S545-GB5 Autonics A10K-S545-GB5 5-Phase Stepper Motor Driver The Autonics A10K-S545-GB5 5-Phase Stepper Motor Driver offers 97.5mm motor length, Single shaft type, Pentagon wire connection, 0.75A/Phase current. Manufactured by Autonics under the 5-Phase Stepper Motor Driver category, this model belongs to the Autonics AK Series.
Brand Autonics Product Type 5-Phase Stepper Motor Driver Model Number A10K-S545-GB5
Autonics A10K-S545-GB5 5-Phase Stepper Motor Driver – Technical Specifications Specification Value Motor length 97.5mm Shaft type Single shaft Wire connection Pentagon Rated current 0.75A/Phase Basic Step Angle [FULL/HALF] 0.144º/0.072º Rotor Moment Of Inertia 68g·cm² Winding Resistance 2.2Ω Protection structure IP30 ElectroMagnetic brake_Rated excitation voltage 24VDC @(=)±10%(no-polarity) ElectroMagnetic brake_Rated excitation current 0.2A ElectroMagnetic brake_Static friction torque 1.8kgf.cm ElectroMagnetic brake_Rotation part inertia moment 3×10@(^-7)kgf.cm² ElectroMagnetic brake_B type brake Power on: brake is released, power off: brake is operating ElectroMagnetic brake_Operating time Max. 15ms ElectroMagnetic brake_Releasing time Max. 25ms Max. allowable torque 10kgf.cm Reduction ratio 1:5 Allowable speed range 0 to 360rpm Backlash ±35'(0.58˚) Weight Approx. 0.78kg(approx. 0.72kg)
