Aims Control Single Block & Bleed Valve
Technical Specifications of AIMS Control Single Block & Bleed Valve:
| Spec | Value |
|---|
| Brand Name | AIMS Controls |
| Product Name | Valves |
| Description | Block & Bleed valve, Back seating to prevent stem blow-out, M8 x 1mm (F) plugged drain. |
AIMS Control Single Block & Bleed Valve Technical Specifications
| Specification | Value |
|---|
| Brand Name | AIMS Controls |
| Product Name | Valves |
| Description | Block & Bleed valve, Back seating to prevent stem blow-out, M8 x 1mm (F) plugged drain. |
| Stem type | Hard seated stem |
| Wetted parts | AISI 316 SS, AISI 316L SS, Monel |
| Max. working temperature | 240°C |
| Max. working pressure | 413.7 bar (6000 psi) |
| Stem | Conical metal tip |
