Home Brands Wenglor Through-Beam Sensors EO98VB3 Wenglor EO98VB3 Photoelectric Sensor The Wenglor EO98VB3 Photoelectric Sensor offers 10,000 mm range, Receiver sensor type, 10 ... 30 V DC supply voltage, IP67 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Through-Beam Series .
Brand Wenglor Product Type Through-Beam Sensors Model Number EO98VB3
Wenglor EO98VB3 Photoelectric Sensor – Technical Specifications Specification Value Range 10,000 mm Light Source Infrared Light Service Life (T = +25 °C) 100,000 h Sensor Type Receiver Supply Voltage 10 ... 30 V DC Current Consumption (Ub = 24 V) < 40 mA Temperature Drift < 10 % Temperature Range -10 ... 60 °C Reverse Polarity Protection yes Protection Class III Housing Material Brass, nickel-plated Degree of Protection IP67 Connection M12 × 1; 4-pin Weight 16 g MTTFd (EN ISO 13849-1) 4,237.93 a Switching Hysteresis < 15 % Max. Ambient Light 10,000 Lux Switching Frequency 250 Hz Response Time 2 ms Switching Output Voltage Drop < 2.5 V Switching Output/Switching Current 200 mA Residual Current Switching Output < 50 µA Short Circuit Protection yes Overload Protection yes Setting Method Potentiometer PNP NO yes Opening Angle 8 ° Full Encapsulation yes
