WTB12-3P2461S58: 1047850 - Sick 700 µs Response Time Photo Sensor

Technical Specifications of Sick 700 µs Response Time Photo Sensor WTB12-3P2461S58 1047850:
Spec | Value |
---|---|
Dimensions (W x H x D) | 15.6 mm x 48.5 mm x 42 mm |
Sensing Range | 50 mm ... 500 mm |
Digital Output Type | PNP |
Connection | Male connector M12, 4-pin |
Sick 700 µs Response Time Photo Sensor WTB12-3P2461S58, 1047850 Technical Specifications:
Specification | Value |
---|---|
Functional principle | Photoelectric proximity sensor |
Functional principle detail | Background suppression |
Sensing range max. | 30 mm ... 500 mm 1) |
Sensing range | 50 mm ... 500 mm |
Polarisation filters | - |
Light source | PinPoint LED 2) |
Type of light | Visible red light |
Light spot size (distance) | 50 mm x 5 mm (150 mm) |
Wave length | - |
Adjustment | Potentiometer, 5 turns |
Angle of dispersion | - |
Special applications | Detecting perforated objects, Detecting objects with position tolerances, Detecting objects wrapped in film, Detecting uneven, shiny objects |
Items supplied | - |
Supply voltage UB | 10 V DC ... 30 V DC 1) |
Ripple | < 5 Vpp 2) |
Current consumption | 40 mA 3) |
Protection class | III |
Digital Output type | PNP |
Switching mode | Light/dark switching |
Signal voltage PNP HIGH/LOW | > Uv - 2,5 V / ca. 0 V |
Output current Imax. | ≤ 100 mA |
Response time | ≤ 700 µs 4) |
Switching frequency | 750 Hz 5) |
Output function | Complementary |
Special feature | Line-shaped light spot |
Housing | Rectangular |
Dimensions (W x H x D) | 15.6 mm x 48.5 mm x 42 mm |
Connection | Male connector M12, 4-pin |
Housing material | Metal |
Front screen material | Plastic, PMMA |
Enclosure rating | IP66, IP67, IP69K |
Ambient operating temperature | –40 °C ... +60 °C |
Ambient temperature, storage | –40 °C ... +75 °C |
Weight | 120 g |
Talk to Our Engineer for Sick 700 µs Response Time Photo Sensor WTB12-3P2461S58 part no: 1047850 with exclusive offers. Core System Specifications of WTB12-3P2461S58, 1047850 are Photoelectric proximity sensor, Background suppression, 50 mm ... 500 mm sensing range, PinPoint LED 2) light source, Visible red light, 50 mm x 5 mm (150 mm) light spot size, - wave length, 10 V DC ... 30 V DC 1) supply voltage, < 5 Vpp 2) ripple, 40 mA 3) current consumption, PNP, Complementary output, Light/dark switching , ≤ 100 mA, ≤ 700 µs 4) response time, 750 Hz 5) frequency, Rectangular housing, 15.6 mm x 48.5 mm x 42 mm dimensions, Male connector M12, 4-pin. Don't Miss Out on a Quote for your requirement of Sick 700 µs Response Time Photo Sensor. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
