WS/WE12L-2P430: 1018254 - Sick 80m Through-beam Photo Sensor
Technical Specifications of Sick 80m Through-beam Photo Sensor WS/WE12L-2P430 1018254:
| Spec | Value |
|---|---|
| Dimensions (W x H x D) | 15 mm x 49 mm x 41.5 mm |
| Sensing Range | - |
| Digital Output Type | PNP |
| Connection | Male connector M12, 4-pin |
Sick 80m Through-beam Photo Sensor WS/WE12L-2P430, 1018254 Technical Specifications:
| Specification | Value |
|---|---|
| Functional principle | Through-beam photoelectric sensor |
| Functional principle detail | - |
| Sensing range max. | 0 m ... 80 m |
| Sensing range | - |
| Polarisation filters | - |
| Light source | Laser |
| Type of light | Visible red light |
| Light spot size (distance) | Ø 150 mm (60 m) |
| Wave length | 650 nm |
| Adjustment | Potentiometer |
| Angle of dispersion | - |
| Special applications | Detecting small objects, Detection of objects moving at high speeds |
| Items supplied | 2 x clamps BEF-KH-W12, incl. screws |
| Supply voltage UB | 10 V DC ... 30 V DC 1) |
| Ripple | < 5 Vpp 2) |
| Current consumption | 45 mA 3) |
| Protection class | III |
| Digital Output type | PNP |
| Switching mode | - |
| Signal voltage PNP HIGH/LOW | Uv - < 2.9 V, Uv V / 0 V <= 1.5 V |
| Output current Imax. | ≤ 100 mA |
| Response time | ≤ 200 µs 4) |
| Switching frequency | 2,500 Hz 5) |
| Output function | Complementary |
| Special feature | - |
| Housing | Rectangular |
| Dimensions (W x H x D) | 15 mm x 49 mm x 41.5 mm |
| Connection | Male connector M12, 4-pin |
| Housing material | Metal |
| Front screen material | Plastic, PMMA |
| Enclosure rating | IP67, IP69K |
| Ambient operating temperature | –10 °C ... +50 °C |
| Ambient temperature, storage | –25 °C ... +75 °C |
| Weight | 260 g |
Obtain a Quote for Sick 80m Through-beam Photo Sensor WS/WE12L-2P430 part no: 1018254 at economical prices. Specifications Overview for WS/WE12L-2P430, 1018254 reveals Through-beam photoelectric sensor, -, 0 m ... 80 m sensing range, Laser light source, Visible red light, Ø 150 mm (60 m) light spot size, 650 nm wave length, 10 V DC ... 30 V DC 1) supply voltage, < 5 Vpp 2) ripple, 45 mA 3) current consumption, PNP output, - , ≤ 100 mA, ≤ 200 µs 4) response time, 2,500 Hz 5) frequency, Rectangular housing, 15 mm x 49 mm x 41.5 mm dimensions, Male connector M12, 4-pin. Take the First Step with a Quote for your requirement of Sick 80m Through-beam Photo Sensor. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
